xTool S1 Settings: 20W & 40W Cutting Rows

xTool documents 10 speed and power settings for the xTool S1. CutChart has not tested them; it read the maker’s documents on 2026-10-02.

Diode only · safety ↓ · sources ↓

Shopping for this model or its accessories? Check the model-specific Amazon options (shopping links; disclosure at that section).

10 documented rows match these filters.

Source-documented settings for the xTool S1

About these numbers

Manufacturer-published reference parameters, not tested by CutChart

Speed: the figure the publisher printed, in bold, with mm/min converted under it. Type the number whose unit matches the speed box in your laser software. Not sure? Convert it here.

xTool S1 20W blue module

xTool S1 20W blue module · Lindenholz (basswood, as printed)

xTool S1 20W blue module, Lindenholz: 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
xTool S1 20W blue module3 mmLindenholzcut7 mm/s = 420 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 20W blue module6 mmLindenholzcut4 mm/s = 240 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 20W blue module10 mmLindenholzcut3 mm/s = 180 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

xTool S1 20W blue module · Schwarzes Acryl

xTool S1 20W blue module, Schwarzes Acryl: 1 row, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
xTool S1 20W blue module3 mmSchwarzes Acrylcut4 mm/s = 240 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: cut · 1 pass

Not specified by xTool for any row here: air assist, focus and lens.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

xTool S1 40W blue module

xTool S1 40W blue module · Lindenholz (basswood, as printed)

xTool S1 40W blue module, Lindenholz: 4 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
xTool S1 40W blue module3 mmLindenholzcut15 mm/s = 900 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module6 mmLindenholzcut10 mm/s = 600 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module10 mmLindenholzcut6 mm/s = 360 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module15 mmLindenholzcut2 mm/s = 120 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

xTool S1 40W blue module · Schwarzes Acryl

xTool S1 40W blue module, Schwarzes Acryl: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
xTool S1 40W blue module3 mmSchwarzes Acrylcut8 mm/s = 480 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module6 mmSchwarzes Acrylcut2 mm/s = 120 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: cut · 1 pass

Not specified by xTool for any row here: air assist, focus and lens.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

Documented machine and module ratings

Power ratings by model

Select a model above to save its full source record.

3 configurations with source records

3 configurations with source records
Machine / moduleOptical or emitted powerElectrical / machine inputManufacturer label
xTool S1 10W blue moduleRead 2026-09-2110 W (xTool, 2026-09-21)The reviewed SOP gives laser power, not total electrical input.10 W (xTool, 2026-09-21)
xTool S1 20W blue moduleRead 2026-09-2120 W (xTool, 2026-09-21)The reviewed SOP gives laser power, not total electrical input.20 W (xTool, 2026-09-21)
xTool S1 40W blue moduleRead 2026-09-2140 W (xTool, 2026-09-21)The reviewed SOP gives laser power, not total electrical input.40 W (xTool, 2026-09-21)

Admitted comparisons for these configurations

Material safety statements from the sources

Quoted from laser makers' documents about each material. Not a complete safety procedure.

Acrylic

Fire risk · 3 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Introduction”: Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Wood

Fire risk and ventilate · 5 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Ventilation: Creality, under “Security Statement”: Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Common questions

Can I use a row on another machine?

Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.

Why are some fields marked not specified?

The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.

Why are some combinations absent?

CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.

Source documents

Sources (3)
Epilog Laser: Reducing Fire Hazards with your Laser (3 excerpts)

Reducing Fire Hazards with your Laser

Publication date not printed by Epilog Laser · Read · Captured

  1. Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser.

    Epilog Laser, Reducing Fire Hazards with your Laser, Introduction. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Creality: Creality Falcon2 (12W/22W/40W) User Manual (3 excerpts)

Creality Falcon2 (12W/22W/40W) User Manual

Publication date not printed by Creality · Read · Captured

  1. When a laser engraver engraves or cuts materials, it casts a high-density laser beam that heats the surface to vaporize materials without burning them. But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. 14. It is forbidden to leave it unattended while the machine is working.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. 11. Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

xTool: Materialeinstellungen für xTool Maschinen (10 excerpts)

Materialeinstellungen für xTool Maschinen

Publication date not printed by xTool · Read · Captured

  1. Lindenholz | 10.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100/ 3 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Lindenholz | 3.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 7 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Lindenholz | 6.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 4 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Schwarzes Acryl | 3.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 4 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Lindenholz | 10.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 6 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  6. Lindenholz | 15.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 2 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  7. Lindenholz | 3.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 15 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  8. Lindenholz | 6.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 10 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  9. Schwarzes Acryl | 3.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 8 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  10. Schwarzes Acryl | 6.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 2 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Cite this page: xTool S1 Settings: 20W & 40W Cutting Rows. CutChart. https://cutchart.com/machines/xtool-s1/ (sources read 2026-10-02).

Accessory fit and replacement parts

Identify the machine and accessory together before buying.

Accessory or partDocumented scopeBefore ordering
xTool RA2 Pro rotaryxTool names the S1 in its RA2 Pro compatibility list. Its S1 rotary quick start is a separate setup reference. xTool RA2 Pro documentation.Confirm RA2 Pro versus roller-only RA2, the S1 connection cable, riser requirements and included parts against the S1 guide.
Honeycomb Panel for S1xTool lists the panel dimensions as 565 × 375 × 27 mm and names the S1. xTool UK panel specifications.Choose the S1 panel. An external size or another xTool model name alone does not prove fit.
S1 panel and riser combinationxTool lists material height above zero through 15 mm with the honeycomb panel, and above zero through 99 mm with the riser base and honeycomb panel. These are supported material heights, not cutting depths. xTool S1 flat-surface configurations.Use the row for the installed base, panel and riser. Keep the conveyor configuration separate.
Air Assist Set for S1xTool identifies the S1 air-assist set in its S1 20W/40W troubleshooting instructions. xTool S1 troubleshooting.Match the S1 kit and its included connections. A generic pump flow claim does not establish electronic control or fit.

Rows describe manufacturer documentation. CutChart has not installed these accessories or tested their fit, and a listed accessory does not supply settings, material safety approval or a promise about the finished work.

Keep maintenance tied to the part

For the S1 20W and 40W modules, xTool distinguishes a dirty protective lens, a burnt protective lens and a damaged inner lens. Its instructions call for cleaning the dirty protective lens, replacing a burnt protective lens, and contacting xTool about a burnt or broken inner lens. Follow the linked manufacturer procedure before buying an optic.

Record the part number, machine revision, existing dimensions and the maker’s replacement procedure. Treat an unlisted fit as unknown. A seller’s use of the word universal does not establish a matching connector, focal length, wavelength or mounting thread.

For sheet identity and thickness, use the material buying checklist. Keep a purchase separate from the steps for recording a failed cut and the documented material operations.
