Optical Watt Decoder: Read Laser Power Ratings

Read the optical output, electrical input and wattage label for the exact laser module. This decoder shows documented specifications and flags missing or conflicting values. It does not turn input power into emitted power or predict a cutting thickness. Match the model and module to the label on your machine.

CutChart editorialUpdated 2026-09-20

Read the power specification

Select the model and module printed on your machine. An entered wattage does not change the manufacturer's specification.

ModelModule or configurationAdvertised wattage, optional (W)

Choose a documented model and its exact module. A wattage label alone cannot identify optical output.

Documented machine and module ratings

This catalog keeps the manufacturer's three power fields separate. A missing optical measurement stays missing; a conflicting label stays visible. Sources were reviewed on 2026-09-21.

On a narrow screen, scroll the table sideways. Select a model above to save its full source record.

19 configurations with source records
Machine / module	Optical or emitted power	Electrical / machine input	Manufacturer label
Boss LS-1630 105W optionRead 2026-09-21	Both sources label tube watts; neither supplies an optical measurement basis.	No electrical input watts in the reviewed specification.	105 W (Boss Laser, 2026-09-21)
Boss LS-1630 base configurationRead 2026-09-21	The product page lists 80W while its linked specification PDF lists 70W. LS-1630 Co2 Laser Cutter and Engraver (2026-09-21). BOSS LS-1630 (2026-09-21).	No electrical input watts in the reviewed specification.	80 W (Boss Laser, 2026-09-21)
Falcon2 12WRead 2026-09-21	12 W (Creality Falcon, 2026-09-21)	120 W (Creality Falcon, 2026-09-21)	12 W (Creality Falcon, 2026-09-21)
Falcon2 22WRead 2026-09-21	22 W (Creality Falcon, 2026-09-21)	120 W (Creality Falcon, 2026-09-21)	22 W (Creality Falcon, 2026-09-21)
Falcon2 40W (Normal mode)Read 2026-09-21	40 W (Creality Falcon, 2026-09-21)	240 W (Creality Falcon, 2026-09-21)	40 W (Creality Falcon, 2026-09-21)
Monport 40W CO2 Laser EngraverRead 2026-09-21	The parameter sheet names the machine by its marketed watts without an optical measurement basis.	Electrical input is not printed in the parameter sheet.	40 W (Monport, 2026-09-21)
ONYX-RRead 2026-09-21	The specification table prints Rated Power without an optical measurement basis.	550 W (Monport, 2026-09-21)	55 W (Monport, 2026-09-21)
OMTech Maker MF1624-60Read 2026-09-21	The comparison labels this Laser Power without specifying an optical measurement basis.	Electrical input is not listed in the comparison.	60 W (OMTech, 2026-09-21)
OMTech Polar 350Read 2026-09-21	The comparison labels this Laser Power without specifying an optical measurement basis.	Electrical input is not listed in the comparison.	50 W (OMTech, 2026-09-21)
LU2-10A (10W)Read 2026-09-21	The settings table labels the module by watts without stating a measurement basis.	Electrical input is not listed in the settings table.	10 W (Ortur, 2026-09-21)
LU3-20A/B (20W)Read 2026-09-21	The settings table labels the module by watts without stating a measurement basis.	Electrical input is not listed in the settings table.	20 W (Ortur, 2026-09-21)
LU3-40A (40W)Read 2026-09-21	The settings table labels the module by watts without stating a measurement basis.	Electrical input is not listed in the settings table.	40 W (Ortur, 2026-09-21)
D1 Pro 10WRead 2026-09-21	The settings table labels the module by watts without stating a measurement basis.	Electrical input is not listed in the settings table.	10 W (xTool, 2026-09-21)
D1 Pro 20WRead 2026-09-21	The settings table labels the module by watts without stating a measurement basis.	Electrical input is not listed in the settings table.	20 W (xTool, 2026-09-21)
D1 Pro 40WRead 2026-09-21	The settings table labels the module by watts without stating a measurement basis.	Electrical input is not listed in the settings table.	40 W (xTool, 2026-09-21)
D1 Pro 5WRead 2026-09-21	The settings table labels the module by watts without stating a measurement basis.	Electrical input is not listed in the settings table.	5 W (xTool, 2026-09-21)
xTool S1 10W blue moduleRead 2026-09-21	10 W (xTool, 2026-09-21)	The reviewed SOP gives laser power, not total electrical input.	10 W (xTool, 2026-09-21)
xTool S1 20W blue moduleRead 2026-09-21	20 W (xTool, 2026-09-21)	The reviewed SOP gives laser power, not total electrical input.	20 W (xTool, 2026-09-21)
xTool S1 40W blue moduleRead 2026-09-21	40 W (xTool, 2026-09-21)	The reviewed SOP gives laser power, not total electrical input.	40 W (xTool, 2026-09-21)

Match the question to the evidence

A machine specification describes a rating. A cutting recipe needs the material and operating conditions too. Read what each laser can cut or mark before using watts as a material claim.

For a failed cut, use the troubleshooting checks. To compare speed units in a document, use the speed converter.

Our source process explains document scope. The tools hub lists the available lookups.

Common questions

Can electrical input watts be converted into optical watts?

CutChart does not infer that conversion. The tool displays an optical or emitted-power value only when the cited document identifies it.

How thick can a 40W laser cut?

A power label alone cannot answer that question. You need a documented cutting result for the exact module, material, thickness and configuration. This decoder does not predict cutting depth.

Why do some configurations show a missing or conflicting value?

The source may label tube power without stating an optical measurement basis, or two documents may disagree. The decoder keeps that limitation beside the source instead of guessing.

Source documents

Boss Laser: LS-1630 Co2 Laser Cutter and Engraver

LS-1630 Co2 Laser Cutter and Engraver · FEATURES

Publication date not printed by Boss Laser · Read 2026-09-21 · Captured 2026-09-21

80, or 105W CO2 laser tube
