xTool S1 Settings for Wood: 3 to 15 mm

xTool documents 7 speed and power settings for wood on the xTool S1. CutChart has not tested them; it read the maker’s documents on 2026-10-02.

Diode only · safety ↓ · sources ↓

Shopping for this model or its accessories? Check the model-specific Amazon options (shopping links; disclosure at that section).

Source-documented settings for wood on the xTool S1

About these numbers

Manufacturer-published reference parameters, not tested by CutChart

Speed: the figure the publisher printed, in bold, with mm/min converted under it. Type the number whose unit matches the speed box in your laser software. Not sure? Convert it here.

Lindenholz (basswood, as printed) · cut · 1 pass

Source-documented settings: 7 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
xTool S1 20W blue module3 mmLindenholzcut7 mm/s = 420 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module3 mmLindenholzcut15 mm/s = 900 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 20W blue module6 mmLindenholzcut4 mm/s = 240 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module6 mmLindenholzcut10 mm/s = 600 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 20W blue module10 mmLindenholzcut3 mm/s = 180 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module10 mmLindenholzcut6 mm/s = 360 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module15 mmLindenholzcut2 mm/s = 120 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Not specified by xTool: air assist, focus and lens.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

Material safety statements from the sources

Quoted from laser makers' documents about each material. Not a complete safety procedure.

Wood

Fire risk and ventilate · 5 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Ventilation: Creality, under “Security Statement”: Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Common questions

Can I use a row on another machine?

Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.

Why are some fields marked not specified?

The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.

Why are some combinations absent?

CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.

Source documents

Sources (3)
Epilog Laser: Reducing Fire Hazards with your Laser (2 excerpts)

Reducing Fire Hazards with your Laser

Publication date not printed by Epilog Laser · Read · Captured

  1. Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Creality: Creality Falcon2 (12W/22W/40W) User Manual (3 excerpts)

Creality Falcon2 (12W/22W/40W) User Manual

Publication date not printed by Creality · Read · Captured

  1. When a laser engraver engraves or cuts materials, it casts a high-density laser beam that heats the surface to vaporize materials without burning them. But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. 14. It is forbidden to leave it unattended while the machine is working.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. 11. Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

xTool: Materialeinstellungen für xTool Maschinen (7 excerpts)

Materialeinstellungen für xTool Maschinen

Publication date not printed by xTool · Read · Captured

  1. Lindenholz | 10.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100/ 3 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Lindenholz | 3.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 7 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Lindenholz | 6.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 4 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Lindenholz | 10.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 6 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Lindenholz | 15.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 2 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  6. Lindenholz | 3.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 15 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  7. Lindenholz | 6.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 10 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
