LightBurn Material Library: save, load and assign

LightBurn's Material Library stores settings you can reuse. Save a layer as a preset, or load a .clb file through Manage Library. Assign copies a preset into a layer; Link keeps the layer tied to it. Keep the source document and exact machine context with your own notes. CutChart cites LightBurn’s own documentation.

CutChart cover card on a dark grid plate: a focus caret aimed at one height on a vertical scale, a software badge, and the printed line "LightBurn Material Library: Save, Load & Assign".
On this page

Save or load a library

Open Window → Library if the panel is hidden. To save a layer, select Create new from layer, then enter its material, thickness and description. Under Manage Library, use Save Library to keep the file, or Load Library to open an existing .clb. These controls come from LightBurn's library reference.

Assign copies the selected preset into the active layer. Later edits to either stay separate. Link connects the layer to the preset: changes to that library entry flow into the linked layer. LightBurn recommends a separate library for each laser. See the Assign, Link and Multiple Lasers sections.

Check the settings in context

Open the Cut Settings Editor by double-clicking a layer or library entry. The available controls depend on the laser type and layer mode. Speed, power and mode sit near the top; other controls appear below. Read LightBurn's editor reference for the controls your device exposes.

Check both parts of a speed unit: distance and time. LightBurn tells readers to match the source units or convert the value. Its speed documentation also explains that a machine may not reach the entered speed. Our speed unit converter handles the arithmetic.

Keep a source note beside the preset

For your own record, write down the exact machine and module, material composition, thickness or coating, operation, and document URL. Add the date you read it. That is CutChart's suggested note format; it is not a statement that LightBurn requires those fields.

CutChart's reference pages are organized on the same fields, one page per material and laser family: the diode family hub and the CO2 family hub list the tables that exist, and every row there carries the publisher and the date beside the value.

A downloaded file can leave unanswered questions. Which machine did the author use? Does the quoted document describe cutting or engraving? Have its conditions been preserved? Our source process explains how we approach those questions. The available tools show what you can check here today.

CutChart has no verified .clb download available yet. We will publish a file only after checking its source settings and import behavior for its stated device. See the scope of CutChart before treating a page as hardware test evidence.

Library loaded, but the cut layer did not change?

Loading a library and applying a preset are separate actions. LightBurn's version 2.1 library guide says to activate the intended layer, select the preset, then use Assign or Link. Opening a .clb file does not by itself establish which layer should use which entry.

On a narrow screen, scroll the table sideways.

What you seeWhat to check next
The library panel is missingOpen Window > Library before looking for presets.
The panel has no expected entriesCheck which library file you loaded and whether it belongs to this laser.
The preset is visible, but the layer has its old settingsSelect the intended layer, then apply the selected preset with Assign or Link.
A linked layer changes when a preset is editedLink keeps that relationship; Assign creates a separate copy instead.

Before using a borrowed library, keep its exact machine, module, material and operation beside the entry. A file that loads successfully is not evidence that its settings suit your machine or material. Do not transfer a preset on wattage alone, and do not turn a units conversion into a new cutting recommendation.

The version 2.1 Material Test reference describes a grid that varies selected parameters. It is a separate feature from loading a library. Follow the exact device and material safety instructions before planning any test; CutChart does not supply a validated test range or promise a result from an imported preset.

Common questions

Does CutChart offer a LightBurn library download?

No. This page explains the feature. CutChart has not released a device-specific .clb file with verified settings and a checked import.

Can the speed converter move a preset to another laser?

It converts units only. It does not establish a suitable power, speed or pass count for another machine.

Laser Speed & Settings Converter

Source documents

Sources (5)
LightBurn Software: Material Library (1 excerpt)

Material Library

Publication date not printed by LightBurn Software · Read

  1. If you have multiple lasers, it's typically best to create a Material Library for each laser.

    LightBurn Software, Material Library, Creating New Material Library Presets; Assign; Link; Managing Material Libraries; Multiple Lasers. Publication date not printed by LightBurn Software · Read . LightBurn describes separate libraries for separate devices. This is software guidance, not a documented cutting recipe.

LightBurn Software: Cut Settings Editor (1 excerpt)

Cut Settings Editor

Publication date not printed by LightBurn Software · Read

  1. The Cut Settings Editor is where you adjust all settings for the layers in your project.

    LightBurn Software, Cut Settings Editor, Cut Settings Editor. Publication date not printed by LightBurn Software · Read . The editor presents different controls for different laser types and layer modes.

LightBurn Software: Main / Shared Settings (1 excerpt)

Main / Shared Settings

Publication date not printed by LightBurn Software · Read

  1. Always pay attention to units of distance and time when entering Speed settings

    LightBurn Software, Main / Shared Settings, Speed. Publication date not printed by LightBurn Software · Read . The speed section calls for matching units or converting them before entering a recommendation.

LightBurn Software: Material Test (1 excerpt)

Material Test

Publication date not printed by LightBurn Software · Read

  1. Use the Param dropdown to select different parameters to test.

    LightBurn Software, Material Test, Using The Material Test Generator. Publication date not printed by LightBurn Software · Read . Version 2.1 software reference, not a tested material range or a cutting result.

LightBurn Software: Material Library (1 excerpt)

Material Library

Publication date not printed by LightBurn Software · Read

  1. Applies the preset settings from the selected entry to the active layer.

    LightBurn Software, Material Library, Assign. Publication date not printed by LightBurn Software · Read . Describes the Assign and Link controls in version 2.1. It does not establish cutting settings for a particular machine.

Reference information only. Follow the instructions for your exact machine and material. A listed setting does not establish that a job is safe. Read the safety limits.
