Wood Laser Engraving & Cutting Settings

Creality Falcon, Monport, OMTech, Ortur and xTool document 57 speed and power settings for wood. CutChart has not tested them; it read the makers’ documents from 2026-09-21 to 2026-10-02.

safety ↓ · sources ↓

57 documented rows match these filters.

Source-documented settings for wood

About these numbers

Manufacturer-published reference parameters, not tested by CutChart

Speed: the figure the publisher printed, in bold, with the other unit converted under it. Type the number whose unit matches the speed box in your laser software. Not sure? Convert it here.

10 machines. Open one to see its settings.

CO2 machines

OMTech Polar 350 · Basswood

OMTech Polar 350, Basswood: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
OMTech Polar 3503 mmBasswoodcut65 mm/s = 3900 mm/min90%Not specified by OMTech
  • Air assist: Not specified by OMTech
  • Focus: Not specified by OMTech
  • Lens: Not specified by OMTech
OMTech, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
OMTech Polar 3503 mmBasswoodengrave500 mm/s = 30000 mm/min50%Not specified by OMTech
  • Air assist: Not specified by OMTech
  • Focus: Not specified by OMTech
  • Lens: Not specified by OMTech
  • Line interval: Not specified by OMTech
OMTech, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: 3 mm

Not specified by OMTech for any row here: passes, air assist, focus and lens; line interval on engrave rows.

Source: OMTech, read 2026-09-21; reviewed 2026-09-21. Document: POLAR 350 | 50W | CO2 Desktop Laser Engraver.

ONYX-R · Basswood

ONYX-R, Basswood: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
ONYX-R3 mmBasswoodcut65 mm/s = 3900 mm/min90%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
ONYX-R3 mmBasswoodengrave500 mm/s = 30000 mm/min50%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
  • Line interval: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

These values are identical to the OMTech Polar 350 table above: both makers' documents print the same numbers.

Every row: 3 mm

Not specified by Monport for any row here: passes, air assist, focus and lens; line interval on engrave rows.

Source: Monport, read 2026-09-21; reviewed 2026-09-21. Document: Model ONYX-R.

Diode machines

Falcon2 12W · Bamboo

Falcon2 12W, Bamboo: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
Falcon2 12W3 mmBamboocut280 mm/min (4.67 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 12W3 mmBambooengrave4000 mm/min (66.67 mm/s)40%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
  • Line interval: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Falcon2 12W · Basswood

Falcon2 12W, Basswood: 6 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
Falcon2 12W2 mmBasswoodcut400 mm/min (6.67 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 12W3 mmBasswoodcut300 mm/min (5 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 12W5 mmBasswoodcut200 mm/min (3.33 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 12W8 mmBasswoodcut250 mm/min (4.17 mm/s)100%2
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 12W10 mmBasswoodcut180 mm/min (3 mm/s)100%3
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 12W2 mmBasswoodengrave4000 mm/min (66.67 mm/s)40%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
  • Line interval: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Not specified by Creality Falcon for any row here: air assist, focus and lens; line interval on engrave rows.

Source: Creality Falcon, read 2026-09-21; reviewed 2026-09-21. Document: CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings.

Falcon2 22W · Bamboo

Falcon2 22W, Bamboo: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
Falcon2 22W3 mmBamboocut450 mm/min (7.5 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 22W3 mmBambooengrave6000 mm/min (100 mm/s)40%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
  • Line interval: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Falcon2 22W · Basswood

Falcon2 22W, Basswood: 6 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
Falcon2 22W2 mmBasswoodcut700 mm/min (11.67 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 22W3 mmBasswoodcut550 mm/min (9.17 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 22W5 mmBasswoodcut400 mm/min (6.67 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 22W8 mmBasswoodcut240 mm/min (4 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 22W10 mmBasswoodcut120 mm/min (2 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 22W2 mmBasswoodengrave6000 mm/min (100 mm/s)40%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
  • Line interval: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: 1 pass

Not specified by Creality Falcon for any row here: air assist, focus and lens; line interval on engrave rows.

Source: Creality Falcon, read 2026-09-21; reviewed 2026-09-21. Document: CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings.

Falcon2 40W (Normal mode) · Bamboo

Falcon2 40W (Normal mode), Bamboo: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
Falcon2 40W (Normal mode)5 mmBamboocut800 mm/min (13.33 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 40W (Normal mode)3 mmBambooengrave6000 mm/min (100 mm/s)25%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
  • Line interval: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Falcon2 40W (Normal mode) · Basswood

Falcon2 40W (Normal mode), Basswood: 7 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
Falcon2 40W (Normal mode)2 mmBasswoodcut1000 mm/min (16.67 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 40W (Normal mode)3 mmBasswoodcut850 mm/min (14.17 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 40W (Normal mode)5 mmBasswoodcut700 mm/min (11.67 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 40W (Normal mode)8 mmBasswoodcut400 mm/min (6.67 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 40W (Normal mode)10 mmBasswoodcut300 mm/min (5 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 40W (Normal mode)15 mmBasswoodcut150 mm/min (2.5 mm/s)100%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Falcon2 40W (Normal mode)2 mmBasswoodengrave6000 mm/min (100 mm/s)25%1
  • Air assist: Not specified by Creality Falcon
  • Focus: Not specified by Creality Falcon
  • Lens: Not specified by Creality Falcon
  • Line interval: Not specified by Creality Falcon
Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: 1 pass

Not specified by Creality Falcon for any row here: air assist, focus and lens; line interval on engrave rows.

Source: Creality Falcon, read 2026-09-21; reviewed 2026-09-21. Document: CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings.

LU2-10A (10W) · Pine

LU2-10A (10W), Pine: 7 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
LU2-10A (10W)3 mmPinecut300 mm/min (5 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU2-10A (10W)5 mmPinecut250 mm/min (4.17 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU2-10A (10W)8 mmPinecut100 mm/min (1.67 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU2-10A (10W)10 mmPinecut100 mm/min (1.67 mm/s)100%2
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU2-10A (10W)12 mmPinecut100 mm/min (1.67 mm/s)100%3
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU2-10A (10W)15 mmPinecut100 mm/min (1.67 mm/s)100%5
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU2-10A (10W)19 mmPinecut100 mm/min (1.67 mm/s)100%8
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: cut

Not specified by Ortur for any row here: air assist, focus and lens.

Source: Ortur, read 2026-09-21; reviewed 2026-09-21. Document: Ortur LightBurn Material Settings.

LU3-20A/B (20W) · Pine

LU3-20A/B (20W), Pine: 7 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
LU3-20A/B (20W)3 mmPinecut500 mm/min (8.33 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)5 mmPinecut350 mm/min (5.83 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)8 mmPinecut200 mm/min (3.33 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)10 mmPinecut150 mm/min (2.5 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)12 mmPinecut100 mm/min (1.67 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)15 mmPinecut100 mm/min (1.67 mm/s)100%2
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)19 mmPinecut100 mm/min (1.67 mm/s)100%3
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: cut

Not specified by Ortur for any row here: air assist, focus and lens.

Source: Ortur, read 2026-09-21; reviewed 2026-09-21. Document: Ortur LightBurn Material Settings.

LU3-40A (40W) · Pine

LU3-40A (40W), Pine: 7 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
LU3-40A (40W)3 mmPinecut700 mm/min (11.67 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-40A (40W)5 mmPinecut500 mm/min (8.33 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-40A (40W)8 mmPinecut300 mm/min (5 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-40A (40W)10 mmPinecut250 mm/min (4.17 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-40A (40W)12 mmPinecut180 mm/min (3 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-40A (40W)15 mmPinecut150 mm/min (2.5 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-40A (40W)19 mmPinecut120 mm/min (2 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: cut · 1 pass

Not specified by Ortur for any row here: air assist, focus and lens.

Source: Ortur, read 2026-09-21; reviewed 2026-09-21. Document: Ortur LightBurn Material Settings.

xTool S1 20W blue module · Lindenholz (basswood, as printed)

xTool S1 20W blue module, Lindenholz: 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
xTool S1 20W blue module3 mmLindenholzcut7 mm/s = 420 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 20W blue module6 mmLindenholzcut4 mm/s = 240 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 20W blue module10 mmLindenholzcut3 mm/s = 180 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: cut · 1 pass

Not specified by xTool for any row here: air assist, focus and lens.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

xTool S1 40W blue module · Lindenholz (basswood, as printed)

xTool S1 40W blue module, Lindenholz: 4 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
xTool S1 40W blue module3 mmLindenholzcut15 mm/s = 900 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module6 mmLindenholzcut10 mm/s = 600 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module10 mmLindenholzcut6 mm/s = 360 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 40W blue module15 mmLindenholzcut2 mm/s = 120 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: cut · 1 pass

Not specified by xTool for any row here: air assist, focus and lens.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

Material safety statements from the sources

Quoted from laser makers' documents about each material. Not a complete safety procedure.

Wood

Fire risk and ventilate · 5 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Ventilation: Creality, under “Security Statement”: Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Common questions

Can I use a row on another machine?

Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.

Why are some fields marked not specified?

The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.

Why are some combinations absent?

CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.

Source documents

Sources (7)
Creality Falcon: CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings (25 excerpts)

CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings

Publication date: 2023-12-23 · Read · Captured

  1. Bamboo | 3 | 100 | 280 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Bamboo | 3 | 40 | 4000 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. 10 | 100 | 180 | 3

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Cutting | Basswood | 2 | 100 | 400 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Engraving | Basswood | 2 | 40 | 4000 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  6. 3 | 100 | 300 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  7. 5 | 100 | 200 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  8. 8 | 100 | 250 | 2

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  9. Bamboo | 3 | 100 | 450 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  10. Bamboo | 3 | 40 | 6000 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  11. 10 | 100 | 120 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  12. Cutting | Basswood | 2 | 100 | 700 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  13. Engraving | Basswood | 2 | 40 | 6000 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  14. 3 | 100 | 550 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  15. 5 | 100 | 400 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  16. 8 | 100 | 240 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  17. Bamboo | 3 | 25 | 6000 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  18. Bamboo | 5 | 100 | 800 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  19. 10 | 100 | 300 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  20. 15 | 100 | 150 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  21. Cutting | Basswood | 2 | 100 | 1000 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  22. Engraving | Basswood | 2 | 25 | 6000 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  23. 3 | 100 | 850 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  24. 5 | 100 | 700 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  25. 8 | 100 | 400 | 1

    Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Epilog Laser: Reducing Fire Hazards with your Laser (2 excerpts)

Reducing Fire Hazards with your Laser

Publication date not printed by Epilog Laser · Read · Captured

  1. Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Creality: Creality Falcon2 (12W/22W/40W) User Manual (3 excerpts)

Creality Falcon2 (12W/22W/40W) User Manual

Publication date not printed by Creality · Read · Captured

  1. When a laser engraver engraves or cuts materials, it casts a high-density laser beam that heats the surface to vaporize materials without burning them. But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. 14. It is forbidden to leave it unattended while the machine is working.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. 11. Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Monport: Model ONYX-R (2 excerpts)

Model ONYX-R

Publication date not printed by Monport · Read · Captured

  1. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

OMTech: POLAR 350 | 50W | CO2 Desktop Laser Engraver (2 excerpts)

POLAR 350 | 50W | CO2 Desktop Laser Engraver

Publication date not printed by OMTech · Read · Captured

  1. Basswood 25 50% 500 100% 45 90% 65 13% 3 400

    OMTech, POLAR 350 | 50W | CO2 Desktop Laser Engraver, Average Engraving Settings. Publication date not printed by OMTech · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Basswood 25 50% 500 100% 45 90% 65 13% 3 400

    OMTech, POLAR 350 | 50W | CO2 Desktop Laser Engraver, Average Engraving Settings. Publication date not printed by OMTech · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Ortur: Ortur LightBurn Material Settings (21 excerpts)

Ortur LightBurn Material Settings

Publication date not printed by Ortur · Read · Captured

  1. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 2

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 3

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 5

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 8

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Image Mode: Line Speed(mm/m): 300mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  6. Image Mode: Line Speed(mm/m): 250mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  7. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  8. Image Mode: Line Speed(mm/m): 150mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  9. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  10. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 2

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  11. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 3

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  12. Image Mode: Line Speed(mm/m): 500mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  13. Image Mode: Line Speed(mm/m): 350mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  14. Image Mode: Line Speed(mm/m): 200mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  15. Image Mode: Line Speed(mm/m): 250mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  16. Image Mode: Line Speed(mm/m): 180mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  17. Image Mode: Line Speed(mm/m): 150mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  18. Image Mode: Line Speed(mm/m): 120mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  19. Image Mode: Line Speed(mm/m): 700mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  20. Image Mode: Line Speed(mm/m): 500mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  21. Image Mode: Line Speed(mm/m): 300mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

xTool: Materialeinstellungen für xTool Maschinen (7 excerpts)

Materialeinstellungen für xTool Maschinen

Publication date not printed by xTool · Read · Captured

  1. Lindenholz | 10.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100/ 3 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Lindenholz | 3.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 7 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Lindenholz | 6.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 4 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Lindenholz | 10.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 6 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Lindenholz | 15.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 2 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  6. Lindenholz | 3.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 15 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  7. Lindenholz | 6.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 10 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Cite this page: Wood Laser Engraving & Cutting Settings. CutChart. https://cutchart.com/settings/wood/ (sources read 2026-09-21 to 2026-10-02).

Check the blank before ordering

Match the supplier’s exact product identifier, composition, finish and stated thickness to your job. Keep the material safety document with that record. CutChart’s settings belong to the material and machine named by the original publisher. A similar shopping title does not establish the same sheet or suitable settings.

The material sourcing and thickness checklist explains what to save, what to measure and when a blank remains unidentified. Leave an unknown coating, adhesive or composition unresolved before using a laser.

Reference information only. Follow the instructions for your exact machine and material. A listed setting does not establish that a job is safe. Read the safety limits.
