Ortur LU2-10A Settings: 1.6 to 19 mm Rows
12 manufacturer-published reference rows for the LU2-10A (10W) from Ortur match this reference, read 2026-09-21. CutChart has not tested them. Each row links to its publisher’s document, and a field that document does not print is shown as not specified. Material safety statements are quoted from Creality, Epilog Laser and xTool.
Documented machine and module ratings
This catalog keeps the manufacturer's three power fields separate. A missing optical measurement stays missing; a conflicting label stays visible. Sources were reviewed on 2026-09-21.
On a narrow screen, scroll the table sideways. Select a model above to save its full source record.
| Machine / module | Optical or emitted power | Electrical / machine input | Manufacturer label |
|---|---|---|---|
| LU2-10A (10W)Read 2026-09-21 | The settings table labels the module by watts without stating a measurement basis. | Electrical input is not listed in the settings table. | 10 W (Ortur, 2026-09-21) |
Material safety statements from the sources
2 materials on this page carry quoted safety statements. Open a material to read its quotes in full.
Plywood
The cited source documents conditions for plywood. They apply to every plywood row on this page.
6 quoted statements for plywood
- Fire:
But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Ventilation:
Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Fire:
It is forbidden to leave it unattended while the machine is working.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Fire:
Never operate the laser system unattended.
(Epilog Laser, Reducing Fire Hazards with your Laser, read 2026-09-21) - Check the composition:
Do not engrave or cut any unknown materials.
(xTool, S1 Safety First (Important), read 2026-09-21) - Check the composition:
To protect your health and the life of your machine, always obtain a MSDS for materials about which you are uncertain.
(Epilog Laser, Material Safety and your Laser, read 2026-09-21)
The cited safety pages name wood but not plywood or its adhesive; the Creality Falcon parameter rows print Walnut Plywood and Rosewood Plywood without a glue type.
Reviewed 2026-09-21; expires 2026-12-20. These statements are quoted from the publisher and are not a complete safety procedure.
Wood
The cited source documents conditions for wood. They apply to every wood row on this page.
6 quoted statements for wood
- Fire:
Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.
(Epilog Laser, Reducing Fire Hazards with your Laser, read 2026-09-21) - Fire:
Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire.
(Epilog Laser, Reducing Fire Hazards with your Laser, read 2026-09-21) - Fire:
But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Ventilation:
Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Fire:
It is forbidden to leave it unattended while the machine is working.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Check the composition:
Do not engrave or cut any unknown materials.
(xTool, S1 Safety First (Important), read 2026-09-21)
Reviewed 2026-09-21; expires 2026-12-20. These statements are quoted from the publisher and are not a complete safety procedure.
Source-documented settings for the LU2-10A (10W)
Manufacturer-published reference parameters, not tested by CutChart
Match the machine, material and operation before reading a value. Speed is shown in the source unit and in mm/s, rounded to two decimals. Each row names its publisher and the date we read the document. A field the publisher does not print is shown as not specified; CutChart never fills it in.
No publisher prints air assist, focus and lens for any row below, so every row repeats that field with the name of its own publisher.
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Fields the table does not print | Source and status |
|---|---|---|---|---|---|---|---|---|
| LU2-10A (10W) | 1.6 mm material | Plywood | cut | 500 mm/min (8.33 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 2.8 mm material | Plywood | cut | 300 mm/min (5 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 3 mm material | Pine | cut | 300 mm/min (5 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 5 mm material | Pine | cut | 250 mm/min (4.17 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 5 mm material | Plywood | cut | 300 mm/min (5 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 8 mm material | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 8 mm material | Plywood | cut | 100 mm/min (1.67 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 10 mm material | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 2 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 10 mm material | Plywood | cut | 100 mm/min (1.67 mm/s) | 100% | 8 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 12 mm material | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 3 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 15 mm material | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 5 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 19 mm material | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 8 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
These are each publisher's own parameters for its machine and material. CutChart has not run them. Confirm the exact material, focus, air assist and lens with the manufacturer before use.
Read the evidence in context
Our source process explains the checks behind a row. The speed converter changes units; it does not move a setting to another machine. Check power labels with the optical-watt decoder, and read the safety limits before choosing a material.
Common questions
Can I use a row on another machine?
Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.
Why are some fields marked not specified?
The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.
Why are some combinations absent?
CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.
Source documents
5 documents behind the rows and safety statements on this page. Open a document to read every excerpt as printed.
Epilog Laser: Reducing Fire Hazards with your Laser (3 excerpts)
Reducing Fire Hazards with your Laser
Publication date not printed by Epilog Laser · Read · Captured
Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.
Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire.
Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Never operate the laser system unattended.
Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Epilog Laser: Material Safety and your Laser (1 excerpt)
Material Safety and your Laser
Publication date not printed by Epilog Laser · Read · Captured
To protect your health and the life of your machine, always obtain a MSDS for materials about which you are uncertain.
Epilog Laser, Material Safety and your Laser, What happens if you engrave or cut something containing hydrogen or vinyl chloride?. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Creality: Creality Falcon2 (12W/22W/40W) User Manual (3 excerpts)
Creality Falcon2 (12W/22W/40W) User Manual
Publication date not printed by Creality · Read · Captured
When a laser engraver engraves or cuts materials, it casts a high-density laser beam that heats the surface to vaporize materials without burning them. But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
14. It is forbidden to leave it unattended while the machine is working.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
11. Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Ortur: Ortur LightBurn Material Settings (12 excerpts)
Ortur LightBurn Material Settings
Publication date not printed by Ortur · Read · Captured
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 2
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 3
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 5
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 8
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 300mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 250mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 8
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 500mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 300mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 300mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
xTool: S1 Safety First (Important) (1 excerpt)
Publication date not printed by xTool · Read · Captured
Do not engrave or cut any unknown materials. Vaporization or melting of many materials, which include but are not limited to PVC and polycarbonate, may release harmful smoke.
xTool, S1 Safety First (Important), 2. Laser safety. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Reference information only. Follow the instructions for your exact machine and material. A listed setting does not establish that a job is safe. Read the safety limits.
