Diode Laser Settings for Wood: Basswood to Pine
Creality Falcon, Ortur and xTool document 53 speed and power settings for wood on diode lasers. CutChart has not tested them; it read the makers’ documents from 2026-09-21 to 2026-10-02.
Source-documented settings for wood on diode lasers
About these numbers
Manufacturer-published reference parameters, not tested by CutChart
Speed: the figure the publisher printed, in bold, with the other unit converted under it. Type the number whose unit matches the speed box in your laser software. Not sure? Convert it here.
8 machines. Open one to see its settings.
Falcon2 12W · Bamboo
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| Falcon2 12W | 3 mm | Bamboo | cut | 280 mm/min (4.67 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | 3 mm | Bamboo | engrave | 4000 mm/min (66.67 mm/s) | 40% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Falcon2 12W · Basswood
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| Falcon2 12W | 2 mm | Basswood | cut | 400 mm/min (6.67 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | 3 mm | Basswood | cut | 300 mm/min (5 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | 5 mm | Basswood | cut | 200 mm/min (3.33 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | 8 mm | Basswood | cut | 250 mm/min (4.17 mm/s) | 100% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | 10 mm | Basswood | cut | 180 mm/min (3 mm/s) | 100% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | 2 mm | Basswood | engrave | 4000 mm/min (66.67 mm/s) | 40% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Not specified by Creality Falcon for any row here: air assist, focus and lens; line interval on engrave rows.
Source: Creality Falcon, read 2026-09-21; reviewed 2026-09-21. Document: CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings.
Falcon2 22W · Bamboo
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| Falcon2 22W | 3 mm | Bamboo | cut | 450 mm/min (7.5 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | 3 mm | Bamboo | engrave | 6000 mm/min (100 mm/s) | 40% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Falcon2 22W · Basswood
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| Falcon2 22W | 2 mm | Basswood | cut | 700 mm/min (11.67 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | 3 mm | Basswood | cut | 550 mm/min (9.17 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | 5 mm | Basswood | cut | 400 mm/min (6.67 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | 8 mm | Basswood | cut | 240 mm/min (4 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | 10 mm | Basswood | cut | 120 mm/min (2 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | 2 mm | Basswood | engrave | 6000 mm/min (100 mm/s) | 40% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Every row: 1 pass
Not specified by Creality Falcon for any row here: air assist, focus and lens; line interval on engrave rows.
Source: Creality Falcon, read 2026-09-21; reviewed 2026-09-21. Document: CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings.
Falcon2 40W (Normal mode) · Bamboo
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| Falcon2 40W (Normal mode) | 5 mm | Bamboo | cut | 800 mm/min (13.33 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | 3 mm | Bamboo | engrave | 6000 mm/min (100 mm/s) | 25% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Falcon2 40W (Normal mode) · Basswood
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| Falcon2 40W (Normal mode) | 2 mm | Basswood | cut | 1000 mm/min (16.67 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | 3 mm | Basswood | cut | 850 mm/min (14.17 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | 5 mm | Basswood | cut | 700 mm/min (11.67 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | 8 mm | Basswood | cut | 400 mm/min (6.67 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | 10 mm | Basswood | cut | 300 mm/min (5 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | 15 mm | Basswood | cut | 150 mm/min (2.5 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | 2 mm | Basswood | engrave | 6000 mm/min (100 mm/s) | 25% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Every row: 1 pass
Not specified by Creality Falcon for any row here: air assist, focus and lens; line interval on engrave rows.
Source: Creality Falcon, read 2026-09-21; reviewed 2026-09-21. Document: CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings.
LU2-10A (10W) · Pine
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| LU2-10A (10W) | 3 mm | Pine | cut | 300 mm/min (5 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 5 mm | Pine | cut | 250 mm/min (4.17 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 8 mm | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 10 mm | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 2 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 12 mm | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 3 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 15 mm | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 5 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU2-10A (10W) | 19 mm | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 8 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Every row: cut
Not specified by Ortur for any row here: air assist, focus and lens.
Source: Ortur, read 2026-09-21; reviewed 2026-09-21. Document: Ortur LightBurn Material Settings.
LU3-20A/B (20W) · Pine
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| LU3-20A/B (20W) | 3 mm | Pine | cut | 500 mm/min (8.33 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-20A/B (20W) | 5 mm | Pine | cut | 350 mm/min (5.83 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-20A/B (20W) | 8 mm | Pine | cut | 200 mm/min (3.33 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-20A/B (20W) | 10 mm | Pine | cut | 150 mm/min (2.5 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-20A/B (20W) | 12 mm | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-20A/B (20W) | 15 mm | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 2 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-20A/B (20W) | 19 mm | Pine | cut | 100 mm/min (1.67 mm/s) | 100% | 3 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Every row: cut
Not specified by Ortur for any row here: air assist, focus and lens.
Source: Ortur, read 2026-09-21; reviewed 2026-09-21. Document: Ortur LightBurn Material Settings.
LU3-40A (40W) · Pine
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| LU3-40A (40W) | 3 mm | Pine | cut | 700 mm/min (11.67 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-40A (40W) | 5 mm | Pine | cut | 500 mm/min (8.33 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-40A (40W) | 8 mm | Pine | cut | 300 mm/min (5 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-40A (40W) | 10 mm | Pine | cut | 250 mm/min (4.17 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-40A (40W) | 12 mm | Pine | cut | 180 mm/min (3 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-40A (40W) | 15 mm | Pine | cut | 150 mm/min (2.5 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| LU3-40A (40W) | 19 mm | Pine | cut | 120 mm/min (2 mm/s) | 100% | 1 |
| Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Every row: cut · 1 pass
Not specified by Ortur for any row here: air assist, focus and lens.
Source: Ortur, read 2026-09-21; reviewed 2026-09-21. Document: Ortur LightBurn Material Settings.
xTool S1 20W blue module · Lindenholz (basswood, as printed)
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| xTool S1 20W blue module | 3 mm | Lindenholz | cut | 7 mm/s = 420 mm/min | 100% | 1 |
| xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| xTool S1 20W blue module | 6 mm | Lindenholz | cut | 4 mm/s = 240 mm/min | 100% | 1 |
| xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| xTool S1 20W blue module | 10 mm | Lindenholz | cut | 3 mm/s = 180 mm/min | 100% | 1 |
| xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Every row: cut · 1 pass
Not specified by xTool for any row here: air assist, focus and lens.
Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.
xTool S1 40W blue module · Lindenholz (basswood, as printed)
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Not printed by the publisher | Source |
|---|---|---|---|---|---|---|---|---|
| xTool S1 40W blue module | 3 mm | Lindenholz | cut | 15 mm/s = 900 mm/min | 100% | 1 |
| xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| xTool S1 40W blue module | 6 mm | Lindenholz | cut | 10 mm/s = 600 mm/min | 100% | 1 |
| xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| xTool S1 40W blue module | 10 mm | Lindenholz | cut | 6 mm/s = 360 mm/min | 100% | 1 |
| xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| xTool S1 40W blue module | 15 mm | Lindenholz | cut | 2 mm/s = 120 mm/min | 100% | 1 |
| xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
Every row: cut · 1 pass
Not specified by xTool for any row here: air assist, focus and lens.
Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.
Material safety statements from the sources
Quoted from laser makers' documents about each material. Not a complete safety procedure.
Wood
Fire risk and ventilate · 5 statements from Creality and Epilog Laser
- Fire: Epilog Laser, under “Warnings and Recommendations”:
Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.
(Reducing Fire Hazards with your Laser, read 2026-09-21) - Fire: Epilog Laser, under “Warnings and Recommendations”:
Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire.
(Reducing Fire Hazards with your Laser, read 2026-09-21) - Fire: Creality, under “Security Statement”:
But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.
(Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Fire: Creality, under “Security Statement”:
It is forbidden to leave it unattended while the machine is working.
(Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Ventilation: Creality, under “Security Statement”:
Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.
(Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
Reviewed 2026-09-21; next review due 2026-12-20.
Common questions
Can I use a row on another machine?
Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.
Why are some fields marked not specified?
The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.
Why are some combinations absent?
CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.
Source documents
Sources (5)
Creality Falcon: CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings (25 excerpts)
CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings
Publication date: 2023-12-23 · Read · Captured
Bamboo | 3 | 100 | 280 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Bamboo | 3 | 40 | 4000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
10 | 100 | 180 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Cutting | Basswood | 2 | 100 | 400 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Engraving | Basswood | 2 | 40 | 4000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
3 | 100 | 300 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
5 | 100 | 200 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
8 | 100 | 250 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Bamboo | 3 | 100 | 450 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Bamboo | 3 | 40 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
10 | 100 | 120 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Cutting | Basswood | 2 | 100 | 700 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Engraving | Basswood | 2 | 40 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
3 | 100 | 550 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
5 | 100 | 400 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
8 | 100 | 240 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Bamboo | 3 | 25 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Bamboo | 5 | 100 | 800 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
10 | 100 | 300 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
15 | 100 | 150 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Cutting | Basswood | 2 | 100 | 1000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Engraving | Basswood | 2 | 25 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
3 | 100 | 850 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
5 | 100 | 700 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
8 | 100 | 400 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Epilog Laser: Reducing Fire Hazards with your Laser (2 excerpts)
Reducing Fire Hazards with your Laser
Publication date not printed by Epilog Laser · Read · Captured
Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.
Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire.
Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Creality: Creality Falcon2 (12W/22W/40W) User Manual (3 excerpts)
Creality Falcon2 (12W/22W/40W) User Manual
Publication date not printed by Creality · Read · Captured
When a laser engraver engraves or cuts materials, it casts a high-density laser beam that heats the surface to vaporize materials without burning them. But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
14. It is forbidden to leave it unattended while the machine is working.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
11. Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Ortur: Ortur LightBurn Material Settings (21 excerpts)
Ortur LightBurn Material Settings
Publication date not printed by Ortur · Read · Captured
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 2
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 3
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 5
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 8
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 300mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 250mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 150mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 2
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 3
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 500mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 350mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 200mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 250mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 180mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 150mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 120mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 700mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 500mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Image Mode: Line Speed(mm/m): 300mm Power Min(%): 100 Perform Multiple Passes: 1
Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
xTool: Materialeinstellungen für xTool Maschinen (7 excerpts)
Materialeinstellungen für xTool Maschinen
Publication date not printed by xTool · Read · Captured
Lindenholz | 10.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100/ 3 / 1
xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Lindenholz | 3.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 7 / 1
xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Lindenholz | 6.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 4 / 1
xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Lindenholz | 10.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 6 / 1
xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Lindenholz | 15.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 2 / 1
xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Lindenholz | 3.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 15 / 1
xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Lindenholz | 6.0 | Vektorschnitt | 40 W Blaulicht-Laser | 100 / 10 / 1
xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Cite this page: Diode Laser Settings for Wood: Basswood to Pine. CutChart. https://cutchart.com/settings/wood/diode/ (sources read 2026-09-21 to 2026-10-02).
Reference information only. Follow the instructions for your exact machine and material. A listed setting does not establish that a job is safe. Read the safety limits.
