What can each laser cut, engrave or mark?

A laser's material range depends on its source and wavelength as well as power. Cutting through a sheet, engraving a surface and marking a coating are separate claims. Manufacturer charts can help narrow the question, but an exact thickness needs evidence for the machine, material and operation together. CutChart publishes only what a manufacturer printed.

On this page

Name the operation before comparing machines

A listing for metal engraving does not answer a metal-cutting question. Epilog's material compatibility chart keeps CO2 cutting and engraving in separate columns. Its fiber table lists engraving. Read those column headings before borrowing a material claim.

On a narrow screen, scroll the table sideways.

Source or familyWhat the cited document supportsWhat still needs evidence
Epilog CO2Acrylic appears under cutting and engraving; glass under engraving.Exact machine, thickness and settings.
Epilog fiberListed stainless-steel grades appear under engraving.Any claim of cutting through that metal.
Blue diode, LightBurn overviewDark materials interact differently from transparent or light-colored materials.Exact module, material color and documented operation.

The table summarizes selected categories from that document and LightBurn's wavelength reference. It is a guide to the next document to read, without speed or power recommendations.

Where CutChart already holds rows for one of those combinations, they sit on the settings pages rather than in this table. CO2 laser settings by material lists the CO2 tables published here today, each row quoted from the machine maker's own document with the date we read it.

Read the source name as carefully as the watts

LightBurn's laser-type reference distinguishes blue diodes from infrared diodes and CO2 sources. A machine name can cover more than one module. Record the installed module before choosing a reference, then check it against the exact variant column in diode laser settings by material.

Use our optical-watt decoder to compare the power fields published for the supported configurations. An electrical input rating cannot fill a missing optical output field. The tool preserves that missing answer.

Make the material question precise

Replace “acrylic” in your job note with the supplier's product and process type. Our cast versus extruded acrylic guide explains why those labels matter for the finish you want, and the published acrylic rows by machine name the machine and material each parameter was printed for.

Replace “metal” with the alloy and the surface treatment named by the supplier. A request to remove a coating and a request to cut a sheet need separate source records. CutChart treats an unmentioned operation as unknown.

That distinction is why the two metal pages here are named for what their sources print: stainless steel engraving settings and anodized aluminum engraving rows. Read the operation column before borrowing either one.

Epilog calls for obtaining the material's safety data sheet. A chart's material name does not establish the composition of an unlabeled offcut, adhesive or coating. Keep the supplier documentation with the machine instructions.

Turn the broad question into a checkable one

Before looking for a recipe, write a sentence with these fields: exact machine and module, exact material, thickness or coating, operation, and intended result. Then ask whether the cited document answers that same sentence.

The source process explains how CutChart checks those matches. If your documented setup fails to cut through, use the troubleshooting guide to organize the problem. A broad capability list cannot diagnose the failed job.

Common questions

Does a metal engraving listing mean the laser cuts metal?

No. Epilog's fiber compatibility table lists engraving. That table does not establish metal cutting thicknesses or settings.

Can a wattage label tell me the maximum cutting thickness?

No. You need a documented result for the exact machine, material, thickness and configuration. CutChart does not calculate a thickness from watts.

Optical Watt Decoder: Read Laser Power Ratings

Source documents

Sources (2)
LightBurn Software: Laser Types (1 excerpt)

Laser Types

Publication date not printed by LightBurn Software · Read

  1. The laser beam is generated by a source that dictates its power and wavelength.

    LightBurn Software, Laser Types, Laser; Wavelength; Power. Publication date not printed by LightBurn Software · Read . Wavelength and source are separate from machine power labels. Broad categories do not establish an exact cutting recipe.

Epilog Laser: Material Compatibility for CO2 and Fiber Laser Engravers (1 excerpt)

Material Compatibility for CO2 and Fiber Laser Engravers

Publication date: 2023-10-22 · Source updated · Read

  1. it is important to obtain the safety data sheet of the material.

    Epilog Laser, Material Compatibility for CO2 and Fiber Laser Engravers, Introduction; CO2 Material Compatibility; Fiber Material Compatibility. Publication date: 2023-10-22 · Source updated · Read . Epilog's chart separates CO2 cutting and engraving from fiber engraving. Its chart is not a universal safety approval.
