xTool D1 Pro Settings: 4 Module Rows
54 manufacturer-published reference rows for the D1 Pro from xTool match this reference, read 2026-09-21. CutChart has not tested them. Each row links to its publisher’s document, and a field that document does not print is shown as not specified. Material safety statements are quoted from Creality, Epilog Laser and xTool.
Documented machine and module ratings
This catalog keeps the manufacturer's three power fields separate. A missing optical measurement stays missing; a conflicting label stays visible. Sources were reviewed on 2026-09-21.
On a narrow screen, scroll the table sideways. Select a model above to save its full source record.
| Machine / module | Optical or emitted power | Electrical / machine input | Manufacturer label |
|---|---|---|---|
| D1 Pro 10WRead 2026-09-21 | The settings table labels the module by watts without stating a measurement basis. | Electrical input is not listed in the settings table. | 10 W (xTool, 2026-09-21) |
| D1 Pro 20WRead 2026-09-21 | The settings table labels the module by watts without stating a measurement basis. | Electrical input is not listed in the settings table. | 20 W (xTool, 2026-09-21) |
| D1 Pro 40WRead 2026-09-21 | The settings table labels the module by watts without stating a measurement basis. | Electrical input is not listed in the settings table. | 40 W (xTool, 2026-09-21) |
| D1 Pro 5WRead 2026-09-21 | The settings table labels the module by watts without stating a measurement basis. | Electrical input is not listed in the settings table. | 5 W (xTool, 2026-09-21) |
Material safety statements from the sources
3 materials on this page carry quoted safety statements. Open a material to read its quotes in full.
Acrylic
The cited source documents conditions for acrylic. They apply to every acrylic row on this page.
6 quoted statements for acrylic
- Fire:
Experience shows that vector cutting with a laser is most likely to produce an open flame. In particular, acrylic has proven to be extremely flammable in vector cutting.
(xTool, S1 Safety First (Important), read 2026-09-21) - Fire:
Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser.
(Epilog Laser, Reducing Fire Hazards with your Laser, read 2026-09-21) - Fire:
Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.
(Epilog Laser, Reducing Fire Hazards with your Laser, read 2026-09-21) - Ventilation:
Ensure that the workspace is well-ventilated so that the generated smoke can be discharged in time.
(xTool, S1 Safety First (Important), read 2026-09-21) - Fire:
It is forbidden to leave it unattended while the machine is working.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Check the composition:
Do not engrave or cut any unknown materials.
(xTool, S1 Safety First (Important), read 2026-09-21)
Reviewed 2026-09-21; expires 2026-12-20. These statements are quoted from the publisher and are not a complete safety procedure.
Paper
The cited source documents conditions for paper. They apply to every paper row on this page.
5 quoted statements for paper
- Fire:
Do not stack materials (especially organic ones, such as paper) around the machine. They may cause the spread of flames and increase the risk of material ignition.
(xTool, S1 Safety First (Important), read 2026-09-21) - Fire:
But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Ventilation:
Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Fire:
It is forbidden to leave it unattended while the machine is working.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Fire:
Prepare fire extinguishers as a backup. Regularly maintain and inspect the fire extinguishers.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
Reviewed 2026-09-21; expires 2026-12-20. These statements are quoted from the publisher and are not a complete safety procedure.
Plywood
The cited source documents conditions for plywood. They apply to every plywood row on this page.
6 quoted statements for plywood
- Fire:
But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Ventilation:
Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Fire:
It is forbidden to leave it unattended while the machine is working.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Fire:
Never operate the laser system unattended.
(Epilog Laser, Reducing Fire Hazards with your Laser, read 2026-09-21) - Check the composition:
Do not engrave or cut any unknown materials.
(xTool, S1 Safety First (Important), read 2026-09-21) - Check the composition:
To protect your health and the life of your machine, always obtain a MSDS for materials about which you are uncertain.
(Epilog Laser, Material Safety and your Laser, read 2026-09-21)
The cited safety pages name wood but not plywood or its adhesive; the Creality Falcon parameter rows print Walnut Plywood and Rosewood Plywood without a glue type.
Reviewed 2026-09-21; expires 2026-12-20. These statements are quoted from the publisher and are not a complete safety procedure.
Source-documented settings for the D1 Pro
Manufacturer-published reference parameters, not tested by CutChart
Match the machine, material and operation before reading a value. Speed is shown in the source unit and in mm/s, rounded to two decimals. Each row names its publisher and the date we read the document. A field the publisher does not print is shown as not specified; CutChart never fills it in.
| Machine | Thickness | Material as printed | Operation | Speed | Power | Passes | Fields the table does not print | Source and status |
|---|---|---|---|---|---|---|---|---|
| D1 Pro 40W | 0.23 mm material | Kraft Paper | cut | 60 mm/s (60 mm/s) | 60% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 2 mm material | Brown Opaque Glossy Acrylic | cut | 5 mm/s (5 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 2 mm material | Brown Opaque Glossy Acrylic | engrave | 40 mm/s (40 mm/s) | 50% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 2 mm material | Brown Opaque Glossy Acrylic | fill | 50 mm/s (50 mm/s) | 40% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Basswood plywood | cut | 3 mm/s (3 mm/s) | 100% | 2 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Birch Plywood | cut | 3 mm/s (3 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Birch Plywood | engrave | 30 mm/s (30 mm/s) | 50% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Birch Plywood | fill | 100 mm/s (100 mm/s) | 80% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Dark Red Acrylic Sheet（Opaque,Glossy) | cut | 3 mm/s (3 mm/s) | 100% | 4 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Dark Red Acrylic Sheet（Opaque,Glossy) | engrave | 40 mm/s (40 mm/s) | 40% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Dark Red Acrylic Sheet（Opaque,Glossy) | fill | 50 mm/s (50 mm/s) | 80% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Fraxinus Mandshurica Plywood | cut | 3 mm/s (3 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Mahogany Plywood | cut | 4 mm/s (4 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Pine Plywood | cut | 4 mm/s (4 mm/s) | 100% | 2 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Red Acrylic Sheet (Transparent, Glossy) | cut | 3 mm/s (3 mm/s) | 100% | 4 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Red Acrylic Sheet (Transparent, Glossy) | engrave | 50 mm/s (50 mm/s) | 40% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Red Acrylic Sheet (Transparent, Glossy) | fill | 50 mm/s (50 mm/s) | 60% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Walnut Plywood | cut | 3 mm/s (3 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Walnut Plywood | engrave | 30 mm/s (30 mm/s) | 50% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | Walnut Plywood | fill | 100 mm/s (100 mm/s) | 80% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 3 mm material | White oak plywood | cut | 3 mm/s (3 mm/s) | 100% | 2 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Basswood plywood | cut | 6 mm/s (6 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Basswood plywood | engrave | 60 mm/s (60 mm/s) | 80% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Basswood plywood | fill | 100 mm/s (100 mm/s) | 60% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Birch Plywood | cut | 6 mm/s (6 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Dark Red Acrylic Sheet（Opaque,Glossy) | cut | 3 mm/s (3 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Dark Red Acrylic Sheet（Opaque,Glossy) | engrave | 40 mm/s (40 mm/s) | 30% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Dark Red Acrylic Sheet（Opaque,Glossy) | fill | 50 mm/s (50 mm/s) | 40% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Fraxinus Mandshurica Plywood | cut | 4 mm/s (4 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Mahogany Plywood | cut | 6 mm/s (6 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Pine Plywood | cut | 5 mm/s (5 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Red Acrylic Sheet (Transparent, Glossy) | cut | 3 mm/s (3 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Red Acrylic Sheet (Transparent, Glossy) | engrave | 40 mm/s (40 mm/s) | 30% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Red Acrylic Sheet (Transparent, Glossy) | fill | 100 mm/s (100 mm/s) | 60% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | Walnut Plywood | cut | 4 mm/s (4 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 3 mm material | White oak plywood | cut | 5 mm/s (5 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | 3 mm material | Basswood plywood | cut | 13 mm/s (13 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | 3 mm material | Black Acrylic | cut | 5 mm/s (5 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | 3 mm material | Blood Red Acrylic | cut | 5 mm/s (5 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | 3 mm material | Cherry Plywood | cut | 12 mm/s (12 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | 3 mm material | Fraxinus Mandshurica Plywood | cut | 12 mm/s (12 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | 3 mm material | Pine Plywood | cut | 12 mm/s (12 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | 3 mm material | Walnut Plywood | cut | 12 mm/s (12 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 5W | 3 mm material | Basswood plywood | cut | 2 mm/s (2 mm/s) | 100% | 2 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 5W | 3 mm material | Cherry Plywood | cut | 2 mm/s (2 mm/s) | 100% | 2 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 5W | 3 mm material | Dark Red Acrylic Sheet（Opaque,Glossy) | cut | 1 mm/s (1 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 5W | 3 mm material | Dark Red Acrylic Sheet（Opaque,Glossy) | fill | 50 mm/s (50 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 5W | 3 mm material | Walnut Plywood | cut | 4 mm/s (4 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 6 mm material | Basswood plywood | cut | 2 mm/s (2 mm/s) | 100% | 4 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | 6 mm material | Walnut Plywood | cut | 60 mm/s (60 mm/s) | 80% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 6 mm material | Basswood plywood | cut | 6 mm/s (6 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 6 mm material | Birch Plywood | cut | 4 mm/s (4 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | 6 mm material | Walnut Plywood | cut | 60 mm/s (60 mm/s) | 80% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | 8 mm material | Basswood plywood | cut | 6 mm/s (6 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
These are each publisher's own parameters for its machine and material. CutChart has not run them. Confirm the exact material, focus, air assist and lens with the manufacturer before use.
Read the evidence in context
Our source process explains the checks behind a row. The speed converter changes units; it does not move a setting to another machine. Check power labels with the optical-watt decoder, and read the safety limits before choosing a material.
Common questions
Can I use a row on another machine?
Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.
Why are some fields marked not specified?
The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.
Why are some combinations absent?
CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.
Source documents
5 documents behind the rows and safety statements on this page. Open a document to read every excerpt as printed.
Epilog Laser: Reducing Fire Hazards with your Laser (3 excerpts)
Reducing Fire Hazards with your Laser
Publication date not printed by Epilog Laser · Read · Captured
Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser.
Epilog Laser, Reducing Fire Hazards with your Laser, Introduction. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.
Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Never operate the laser system unattended.
Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Epilog Laser: Material Safety and your Laser (1 excerpt)
Material Safety and your Laser
Publication date not printed by Epilog Laser · Read · Captured
To protect your health and the life of your machine, always obtain a MSDS for materials about which you are uncertain.
Epilog Laser, Material Safety and your Laser, What happens if you engrave or cut something containing hydrogen or vinyl chloride?. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Creality: Creality Falcon2 (12W/22W/40W) User Manual (4 excerpts)
Creality Falcon2 (12W/22W/40W) User Manual
Publication date not printed by Creality · Read · Captured
13. Prepare fire extinguishers as a backup. Regularly maintain and inspect the fire extinguishers.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
When a laser engraver engraves or cuts materials, it casts a high-density laser beam that heats the surface to vaporize materials without burning them. But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
14. It is forbidden to leave it unattended while the machine is working.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
11. Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
xTool: Material Settings for xTool Machines (54 excerpts)
Material Settings for xTool Machines
Publication date not printed by xTool · Read · Captured
Basswood plywood | 3.0 | Cut | D1 Pro 10W | 100 / 3 / 2
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Basswood plywood | 6.0 | Cut | D1 Pro 10W | 100 / 2 / 4
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Birch Plywood | 3.0 | Cut | D1 Pro 10W | 100 / 3 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Birch Plywood | 3.0 | Vector engrave | D1 Pro 10W | 50 / 30 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Birch Plywood | 3.0 | Raster engrave | D1 Pro 10W | 80 / 100 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Cut | D1 Pro 10W | 100 / 3 / 4
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Vector engrave | D1 Pro 10W | 40 / 40 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Raster engrave | D1 Pro 10W | 80 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Fraxinus Mandshurica Plywood | 3.0 | Cut | D1 Pro 10W | 100 / 3 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Mahogany Plywood | 3.0 | Cut | D1 Pro 10W | 100 / 4 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Pine Plywood | 3.0 | Cut | D1 Pro 10W | 100 / 4 / 2
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Cut | D1 Pro 10W | 100 / 3 / 4
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Vector engrave | D1 Pro 10W | 40 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Raster engrave | D1 Pro 10W | 60 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Walnut Plywood | 3.0 | Cut | D1 Pro 10W | 100 / 3 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Walnut Plywood | 3.0 | Vector engrave | D1 Pro 10W | 50 / 30 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Walnut Plywood | 3.0 | Raster engrave | D1 Pro 10W | 80 / 100 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Walnut Plywood | 6.0 | Cut | D1 Pro 10W | 80 / 60 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
White oak plywood | 3.0 | Cut | D1 Pro 10W | 100 / 3 / 2
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Basswood plywood | 3.0 | Cut | D1 Pro 20W | 100 / 6 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Basswood plywood | 3.0 | Vector engrave | D1 Pro 20W | 80 / 60 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Basswood plywood | 3.0 | Raster engrave | D1 Pro 20W | 60 / 100 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Basswood plywood | 6.0 | Cut | D1 Pro 20W | 100 / 6 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Birch Plywood | 3.0 | Cut | D1 Pro 20W | 100 / 6 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Birch Plywood | 6.0 | Cut | D1 Pro 20W | 100 / 4 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Brown Opaque Glossy Acrylic | 2.0 | Cut | D1 Pro 20W | 100 / 5 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Brown Opaque Glossy Acrylic | 2.0 | Vector engrave | D1 Pro 20W | 50 / 40 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Brown Opaque Glossy Acrylic | 2.0 | Raster engrave | D1 Pro 20W | 40 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Cut | D1 Pro 20W | 100 / 3 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Vector engrave | D1 Pro 20W | 30 / 40 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Raster engrave | D1 Pro 20W | 40 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Fraxinus Mandshurica Plywood | 3.0 | Cut | D1 Pro 20W | 100 / 4 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Mahogany Plywood | 3.0 | Cut | D1 Pro 20W | 100 / 6 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Pine Plywood | 3.0 | Cut | D1 Pro 20W | 100 / 5 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Cut | D1 Pro 20W | 100 / 3 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Vector engrave | D1 Pro 20W | 30 / 40 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Raster engrave | D1 Pro 20W | 60 / 100 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Walnut Plywood | 3.0 | Cut | D1 Pro 20W | 100 / 4 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Walnut Plywood | 6.0 | Cut | D1 Pro 20W | 80 / 60 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
White oak plywood | 3.0 | Cut | D1 Pro 20W | 100 / 5 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Basswood plywood | 3.0 | Cut | D1 Pro 40W | 100 / 13 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Basswood plywood | 8.0 | Cut | D1 Pro 40W | 100 / 6 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Acrylic | 3.0 | Cut | D1 Pro 40W | 100 / 5 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Blood Red Acrylic | 3.0 | Cut | D1 Pro 40W | 100 / 5 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Cherry Plywood | 3.0 | Cut | D1 Pro 40W | 100 / 12 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Fraxinus Mandshurica Plywood | 3.0 | Cut | D1 Pro 40W | 100 / 12 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Kraft Paper | 0.23mm | Cut | D1 Pro 40W | 60 / 60 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Pine Plywood | 3.0 | Cut | D1 Pro 40W | 100 / 12 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Walnut Plywood | 3.0 | Cut | D1 Pro 40W | 100 / 12 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Basswood plywood | 3.0 | Cut | D1 Pro 5W | 100 / 2 / 2
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Cherry Plywood | 3.0 | Cut | D1 Pro 5W | 100 / 2 / 2
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Cut | D1 Pro 5W | 100 / 1 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Raster engrave | D1 Pro 5W | 100 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Walnut Plywood | 3.0 | Cut | D1 Pro 5W | 100 / 4 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
xTool: S1 Safety First (Important) (4 excerpts)
Publication date not printed by xTool · Read · Captured
A high-density laser beam is used by the device to irradiate the material to be cut or engraved, so as to heat up the material surface and vaporize the material without burning. But most materials are inherently flammable and may be ignited to form an open flame that can burn down the device (even if it is made of flame-retardant materials) and its surroundings. Experience shows that vector cutting with a laser is most likely to produce an open flame. In particular, acrylic has proven to be extremely flammable in vector cutting.
xTool, S1 Safety First (Important), 3. Fire safety. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Do not stack materials (especially organic ones, such as paper) around the machine. They may cause the spread of flames and increase the risk of material ignition.
xTool, S1 Safety First (Important), 3. Fire safety. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Do not engrave or cut any unknown materials. Vaporization or melting of many materials, which include but are not limited to PVC and polycarbonate, may release harmful smoke.
xTool, S1 Safety First (Important), 2. Laser safety. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Ensure that the workspace is well-ventilated so that the generated smoke can be discharged in time.
xTool, S1 Safety First (Important), 3. Fire safety. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Reference information only. Follow the instructions for your exact machine and material. A listed setting does not establish that a job is safe. Read the safety limits.
