Diode Laser Settings for Acrylic: Falcon2 & xTool
97 manufacturer-published reference rows from Creality Falcon and xTool match this reference. Each row keeps its exact machine, material, operation, speed and power as printed, with passes where the table prints them, links to the source and states the date we read it. CutChart has not tested these settings. A field the publisher does not print is marked not specified. Material safety statements are quoted from Creality, Epilog Laser and xTool.
Material safety statements from the sources
Acrylic
The cited source documents conditions for acrylic. They apply to every acrylic row on this page.
- Fire:
Experience shows that vector cutting with a laser is most likely to produce an open flame. In particular, acrylic has proven to be extremely flammable in vector cutting.
(xTool, S1 Safety First (Important), read 2026-09-21) - Fire:
Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser.
(Epilog Laser, Reducing Fire Hazards with your Laser, read 2026-09-21) - Fire:
Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.
(Epilog Laser, Reducing Fire Hazards with your Laser, read 2026-09-21) - Ventilation:
Ensure that the workspace is well-ventilated so that the generated smoke can be discharged in time.
(xTool, S1 Safety First (Important), read 2026-09-21) - Fire:
It is forbidden to leave it unattended while the machine is working.
(Creality, Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21) - Check the composition:
Do not engrave or cut any unknown materials.
(xTool, S1 Safety First (Important), read 2026-09-21)
Reviewed 2026-09-21; expires 2026-12-20. These statements are quoted from the publisher and are not a complete safety procedure.
Source-documented settings
Manufacturer-published reference parameters, not tested by CutChart
Match the machine, material and operation before reading a value. Speed is shown in the source unit and in mm/s, rounded to two decimals. Each row names its publisher and the date we read the document. A field the publisher does not print is shown as not specified; CutChart never fills it in.
97 documented rows match these filters.
2 mm material
| Machine | Material as printed | Operation | Speed | Power | Passes | Fields the table does not print | Source and status |
|---|---|---|---|---|---|---|---|
| D1 Pro 20W | Brown Opaque Glossy Acrylic | cut | 5 mm/s (5 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | Brown Opaque Glossy Acrylic | fill | 50 mm/s (50 mm/s) | 40% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | Brown Opaque Glossy Acrylic | engrave | 40 mm/s (40 mm/s) | 50% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
3 mm material
| Machine | Material as printed | Operation | Speed | Power | Passes | Fields the table does not print | Source and status |
|---|---|---|---|---|---|---|---|
| Falcon2 12W | Black Opaque Glossy Acrylic | engrave | 4000 mm/min (66.67 mm/s) | 80% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Purple Opaque Glossy Acrylic | engrave | 4000 mm/min (66.67 mm/s) | 50% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Red Opaque Glossy Acrylic | engrave | 4000 mm/min (66.67 mm/s) | 50% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Orange Opaque Glossy Acrylic | engrave | 4000 mm/min (66.67 mm/s) | 50% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Green Opaque Glossy Acrylic | engrave | 4000 mm/min (66.67 mm/s) | 50% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Red Transparent Acrylic | engrave | 3000 mm/min (50 mm/s) | 40% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Yellow Transparent Acrylic | engrave | 3000 mm/min (50 mm/s) | 40% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Green Transparent Acrylic | engrave | 3000 mm/min (50 mm/s) | 40% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Black Frosted Acrylic | engrave | 3000 mm/min (50 mm/s) | 80% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Orange Frosted Acrylic | engrave | 1200 mm/min (20 mm/s) | 90% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Green Frosted Acrylic | engrave | 1200 mm/min (20 mm/s) | 90% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Purple Frosted Acrylic | engrave | 1000 mm/min (16.67 mm/s) | 90% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Purple Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Red Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Orange Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Green Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Red Transparent Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Yellow Transparent Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Green Transparent Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Black Frosted Acrylic | cut | 200 mm/min (3.33 mm/s) | 95% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Orange Frosted Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Green Frosted Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 12W | Purple Frosted Acrylic | cut | 120 mm/min (2 mm/s) | 95% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Black Opaque Glossy Acrylic | engrave | 4000 mm/min (66.67 mm/s) | 50% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Purple Opaque Glossy Acrylic | engrave | 6000 mm/min (100 mm/s) | 50% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Red Opaque Glossy Acrylic | engrave | 6000 mm/min (100 mm/s) | 50% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Orange Opaque Glossy Acrylic | engrave | 6000 mm/min (100 mm/s) | 50% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Green Opaque Glossy Acrylic | engrave | 6000 mm/min (100 mm/s) | 50% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Red Transparent Acrylic | engrave | 3000 mm/min (50 mm/s) | 20% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Yellow Transparent Acrylic | engrave | 3000 mm/min (50 mm/s) | 20% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Green Transparent Acrylic | engrave | 3000 mm/min (50 mm/s) | 20% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Black Frosted Acrylic | engrave | 3000 mm/min (50 mm/s) | 40% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Orange Frosted Acrylic | engrave | 1200 mm/min (20 mm/s) | 60% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Green Frosted Acrylic | engrave | 1200 mm/min (20 mm/s) | 60% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Purple Frosted Acrylic | engrave | 1000 mm/min (16.67 mm/s) | 60% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Purple Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Red Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Orange Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Green Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Red Transparent Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Yellow Transparent Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Green Transparent Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Black Frosted Acrylic | cut | 180 mm/min (3 mm/s) | 55% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Orange Frosted Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Green Frosted Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Purple Frosted Acrylic | cut | 120 mm/min (2 mm/s) | 55% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Black Opaque Glossy Acrylic | engrave | 4000 mm/min (66.67 mm/s) | 26% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Purple Opaque Glossy Acrylic | engrave | 6000 mm/min (100 mm/s) | 26% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Red Opaque Glossy Acrylic | engrave | 6000 mm/min (100 mm/s) | 26% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Orange Opaque Glossy Acrylic | engrave | 6000 mm/min (100 mm/s) | 26% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Green Opaque Glossy Acrylic | engrave | 6000 mm/min (100 mm/s) | 26% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Red Transparent Acrylic | engrave | 3000 mm/min (50 mm/s) | 12% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Yellow Transparent Acrylic | engrave | 3000 mm/min (50 mm/s) | 12% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Green Transparent Acrylic | engrave | 3000 mm/min (50 mm/s) | 12% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Black Frosted Acrylic | engrave | 3000 mm/min (50 mm/s) | 22% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Orange Frosted Acrylic | engrave | 1200 mm/min (20 mm/s) | 30% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Green Frosted Acrylic | engrave | 1200 mm/min (20 mm/s) | 30% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Purple Frosted Acrylic | engrave | 1000 mm/min (16.67 mm/s) | 30% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Purple Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Red Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Orange Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Green Opaque Glossy Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Red Transparent Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Yellow Transparent Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Green Transparent Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Black Frosted Acrylic | cut | 180 mm/min (3 mm/s) | 30% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Orange Frosted Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Green Frosted Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Purple Frosted Acrylic | cut | 120 mm/min (2 mm/s) | 30% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 5W | Dark Red Acrylic Sheet（Opaque,Glossy) | cut | 1 mm/s (1 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 5W | Dark Red Acrylic Sheet（Opaque,Glossy) | fill | 50 mm/s (50 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | Dark Red Acrylic Sheet（Opaque,Glossy) | cut | 3 mm/s (3 mm/s) | 100% | 4 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | Dark Red Acrylic Sheet（Opaque,Glossy) | fill | 50 mm/s (50 mm/s) | 80% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | Dark Red Acrylic Sheet（Opaque,Glossy) | engrave | 40 mm/s (40 mm/s) | 40% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | Dark Red Acrylic Sheet（Opaque,Glossy) | cut | 3 mm/s (3 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | Dark Red Acrylic Sheet（Opaque,Glossy) | fill | 50 mm/s (50 mm/s) | 40% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | Dark Red Acrylic Sheet（Opaque,Glossy) | engrave | 40 mm/s (40 mm/s) | 30% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | Red Acrylic Sheet (Transparent, Glossy) | cut | 3 mm/s (3 mm/s) | 100% | 4 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | Red Acrylic Sheet (Transparent, Glossy) | fill | 50 mm/s (50 mm/s) | 60% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 10W | Red Acrylic Sheet (Transparent, Glossy) | engrave | 50 mm/s (50 mm/s) | 40% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | Red Acrylic Sheet (Transparent, Glossy) | cut | 3 mm/s (3 mm/s) | 100% | 3 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | Red Acrylic Sheet (Transparent, Glossy) | fill | 100 mm/s (100 mm/s) | 60% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 20W | Red Acrylic Sheet (Transparent, Glossy) | engrave | 40 mm/s (40 mm/s) | 30% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | Black Acrylic | cut | 5 mm/s (5 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| D1 Pro 40W | Blood Red Acrylic | cut | 5 mm/s (5 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| xTool S1 20W blue module | Black acrylic | cut | 4 mm/s (4 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| xTool S1 40W blue module | Black acrylic | cut | 8 mm/s (8 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
4.6 mm material
| Machine | Material as printed | Operation | Speed | Power | Passes | Fields the table does not print | Source and status |
|---|---|---|---|---|---|---|---|
| Falcon2 12W | Black Acrylic | cut | 300 mm/min (5 mm/s) | 100% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Black Acrylic | cut | 120 mm/min (2 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Black Acrylic | cut | 180 mm/min (3 mm/s) | 100% | 1 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
6 mm material
| Machine | Material as printed | Operation | Speed | Power | Passes | Fields the table does not print | Source and status |
|---|---|---|---|---|---|---|---|
| xTool S1 40W blue module | Black acrylic | cut | 2 mm/s (2 mm/s) | 100% | 1 |
| xTool, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
7.6 mm material
| Machine | Material as printed | Operation | Speed | Power | Passes | Fields the table does not print | Source and status |
|---|---|---|---|---|---|---|---|
| Falcon2 12W | Black Acrylic | cut | 250 mm/min (4.17 mm/s) | 100% | 3 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 22W | Black Acrylic | cut | 120 mm/min (2 mm/s) | 100% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
| Falcon2 40W (Normal mode) | Black Acrylic | cut | 120 mm/min (2 mm/s) | 100% | 2 |
| Creality Falcon, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21. |
These are each publisher's own parameters for its machine and material. CutChart has not run them. Confirm the exact material, focus, air assist and lens with the manufacturer before use.
Read the evidence in context
Our source process explains the checks behind a row. The speed converter changes units; it does not move a setting to another machine. Check power labels with the optical-watt decoder, and read the safety limits before choosing a material.
Common questions
Can I use a row on another machine?
Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.
Why are some fields marked not specified?
The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.
Why are some combinations absent?
CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.
Source documents
5 documents behind the rows and safety statements on this page. Open a document to read every excerpt as printed.
Creality Falcon: CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings (75 excerpts)
CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings
Publication date: 2023-12-23 · Read · Captured
Black Acrylic | 4.6 | 100 | 300 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
7.6 | 100 | 250 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Frosted Acrylic | 3 | 95 | 200 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Frosted Acrylic | 3 | 80 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Opaque Glossy Acrylic | 3 | 80 | 4000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Frosted Acrylic | 3 | 95 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Frosted Acrylic | 3 | 90 | 1200 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Opaque Glossy Acrylic | 3 | 95 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Opaque Glossy Acrylic | 3 | 50 | 4000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Transparent Acrylic | 3 | 95 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Transparent Acrylic | 3 | 40 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Frosted Acrylic | 3 | 95 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Frosted Acrylic | 3 | 90 | 1200 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Opaque Glossy Acrylic | 3 | 95 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Opaque Glossy Acrylic | 3 | 50 | 4000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Frosted Acrylic | 3 | 95 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Frosted Acrylic | 3 | 90 | 1000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Opaque Glossy Acrylic | 3 | 95 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Opaque Glossy Acrylic | 3 | 50 | 4000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Opaque Glossy Acrylic | 3 | 95 | 120 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Opaque Glossy Acrylic | 3 | 50 | 4000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Transparent Acrylic | 3 | 95 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Transparent Acrylic | 3 | 40 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Yellow Transparent Acrylic | 3 | 95 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Yellow Transparent Acrylic | 3 | 40 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 12W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Acrylic | 4.6 | 100 | 120 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
7.6 | 100 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Frosted Acrylic | 3 | 55 | 180 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Frosted Acrylic | 3 | 40 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Opaque Glossy Acrylic | 3 | 50 | 4000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Frosted Acrylic | 3 | 55 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Frosted Acrylic | 3 | 60 | 1200 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Opaque Glossy Acrylic | 3 | 55 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Opaque Glossy Acrylic | 3 | 50 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Transparent Acrylic | 3 | 55 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Transparent Acrylic | 3 | 20 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Frosted Acrylic | 3 | 55 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Frosted Acrylic | 3 | 60 | 1200 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Opaque Glossy Acrylic | 3 | 55 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Opaque Glossy Acrylic | 3 | 50 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Frosted Acrylic | 3 | 55 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Frosted Acrylic | 3 | 60 | 1000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Opaque Glossy Acrylic | 3 | 55 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Opaque Glossy Acrylic | 3 | 50 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Opaque Glossy Acrylic | 3 | 55 | 120 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Opaque Glossy Acrylic | 3 | 50 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Transparent Acrylic | 3 | 55 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Transparent Acrylic | 3 | 20 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Yellow Transparent Acrylic | 3 | 55 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Yellow Transparent Acrylic | 3 | 20 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 22W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Acrylic | 4.6 | 100 | 180 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
7.6 | 100 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Frosted Acrylic | 3 | 30 | 180 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Frosted Acrylic | 3 | 22 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Opaque Glossy Acrylic | 3 | 26 | 4000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Frosted Acrylic | 3 | 30 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Frosted Acrylic | 3 | 30 | 1200 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Opaque Glossy Acrylic | 3 | 30 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Opaque Glossy Acrylic | 3 | 26 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Transparent Acrylic | 3 | 30 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Green Transparent Acrylic | 3 | 12 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Frosted Acrylic | 3 | 30 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Frosted Acrylic | 3 | 30 | 1200 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Opaque Glossy Acrylic | 3 | 30 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Orange Opaque Glossy Acrylic | 3 | 26 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Frosted Acrylic | 3 | 30 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Frosted Acrylic | 3 | 30 | 1000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Opaque Glossy Acrylic | 3 | 30 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Purple Opaque Glossy Acrylic | 3 | 26 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Opaque Glossy Acrylic | 3 | 30 | 120 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Opaque Glossy Acrylic | 3 | 26 | 6000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Transparent Acrylic | 3 | 30 | 120 | 3
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Transparent Acrylic | 3 | 12 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Yellow Transparent Acrylic | 3 | 30 | 120 | 2
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Yellow Transparent Acrylic | 3 | 12 | 3000 | 1
Creality Falcon, CrealityFalcon 2 Laser Engraving & Cutting Parameter Settings, Falcon2 40W Laser Engraving & Cutting Parameter Settings. Publication date: 2023-12-23 · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Epilog Laser: Reducing Fire Hazards with your Laser (2 excerpts)
Reducing Fire Hazards with your Laser
Publication date not printed by Epilog Laser · Read · Captured
Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser.
Epilog Laser, Reducing Fire Hazards with your Laser, Introduction. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.
Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Creality: Creality Falcon2 (12W/22W/40W) User Manual (1 excerpt)
Creality Falcon2 (12W/22W/40W) User Manual
Publication date not printed by Creality · Read · Captured
14. It is forbidden to leave it unattended while the machine is working.
Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
xTool: Material Settings for xTool Machines (22 excerpts)
Material Settings for xTool Machines
Publication date not printed by xTool · Read · Captured
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Cut | D1 Pro 10W | 100 / 3 / 4
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Vector engrave | D1 Pro 10W | 40 / 40 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Raster engrave | D1 Pro 10W | 80 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Cut | D1 Pro 10W | 100 / 3 / 4
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Vector engrave | D1 Pro 10W | 40 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Raster engrave | D1 Pro 10W | 60 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Brown Opaque Glossy Acrylic | 2.0 | Cut | D1 Pro 20W | 100 / 5 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Brown Opaque Glossy Acrylic | 2.0 | Vector engrave | D1 Pro 20W | 50 / 40 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Brown Opaque Glossy Acrylic | 2.0 | Raster engrave | D1 Pro 20W | 40 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Cut | D1 Pro 20W | 100 / 3 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Vector engrave | D1 Pro 20W | 30 / 40 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Raster engrave | D1 Pro 20W | 40 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Cut | D1 Pro 20W | 100 / 3 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Vector engrave | D1 Pro 20W | 30 / 40 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Red Acrylic Sheet (Transparent, Glossy) | 3.0 | Raster engrave | D1 Pro 20W | 60 / 100 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black Acrylic | 3.0 | Cut | D1 Pro 40W | 100 / 5 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Blood Red Acrylic | 3.0 | Cut | D1 Pro 40W | 100 / 5 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Cut | D1 Pro 5W | 100 / 1 / 3
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Dark Red Acrylic Sheet（Opaque,Glossy) | 3.0 | Raster engrave | D1 Pro 5W | 100 / 50 / 1
xTool, Material Settings for xTool Machines, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black acrylic | 3.0 | Vector cut | 20 W blue-light laser | 100 / 4 / 1
xTool, Material Settings for xTool Machines, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black acrylic | 3.0 | Vector cut | 40 W blue-light laser | 100 / 8 / 1
xTool, Material Settings for xTool Machines, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Black acrylic | 6.0 | Vector cut | 40 W blue-light laser | 100 / 2 / 1
xTool, Material Settings for xTool Machines, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
xTool: S1 Safety First (Important) (3 excerpts)
Publication date not printed by xTool · Read · Captured
A high-density laser beam is used by the device to irradiate the material to be cut or engraved, so as to heat up the material surface and vaporize the material without burning. But most materials are inherently flammable and may be ignited to form an open flame that can burn down the device (even if it is made of flame-retardant materials) and its surroundings. Experience shows that vector cutting with a laser is most likely to produce an open flame. In particular, acrylic has proven to be extremely flammable in vector cutting.
xTool, S1 Safety First (Important), 3. Fire safety. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Do not engrave or cut any unknown materials. Vaporization or melting of many materials, which include but are not limited to PVC and polycarbonate, may release harmful smoke.
xTool, S1 Safety First (Important), 2. Laser safety. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Ensure that the workspace is well-ventilated so that the generated smoke can be discharged in time.
xTool, S1 Safety First (Important), 3. Fire safety. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
Reference information only. Follow the instructions for your exact machine and material. A listed setting does not establish that a job is safe. Read the safety limits.
