Monport ONYX-R 55W CO2 Settings from the Manual

Monport documents 6 speed and power settings for the ONYX-R. CutChart has not tested them; it read the maker’s documents on 2026-09-21.

safety ↓ · sources ↓

Source-documented settings for the ONYX-R

About these numbers

Manufacturer-published reference parameters, not tested by CutChart

Speed: the figure the publisher printed, in bold, with mm/min converted under it. Type the number whose unit matches the speed box in your laser software. Not sure? Convert it here.

ONYX-R

Acrylic

ONYX-R, Acrylic: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
ONYX-R3 mmAcryliccut35 mm/s = 2100 mm/min90%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
ONYX-R3 mmAcrylicengrave500 mm/s = 30000 mm/min50%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
  • Line interval: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Basswood

ONYX-R, Basswood: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
ONYX-R3 mmBasswoodcut65 mm/s = 3900 mm/min90%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
ONYX-R3 mmBasswoodengrave500 mm/s = 30000 mm/min50%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
  • Line interval: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Leather

ONYX-R, Leather: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
ONYX-R1.5 mmLeathercut80 mm/s = 4800 mm/min90%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
ONYX-R1.5 mmLeatherengrave500 mm/s = 30000 mm/min30%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
  • Line interval: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Not specified by Monport for any row here: passes, air assist, focus and lens; line interval on engrave rows.

Source: Monport, read 2026-09-21; reviewed 2026-09-21. Document: Model ONYX-R.

Documented machine and module ratings

Power ratings by model

Select a model above to save its full source record.

1 configuration with source records

1 configuration with source records
Machine / moduleOptical or emitted powerElectrical / machine inputManufacturer label
ONYX-RRead 2026-09-21The specification table prints Rated Power without an optical measurement basis.550 W (Monport, 2026-09-21)55 W (Monport, 2026-09-21)

Material safety statements from the sources

Quoted from laser makers' documents about each material. Not a complete safety procedure.

Acrylic

Fire risk · 3 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Introduction”: Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Leather

Trotec Laser, under “Materials you should not process with a laser”: Leather and artificial leather that contains chromium (VI)

Caution: Hazard, check what the material is made of, ventilate and fire risk · 6 statements from Creality, Epilog Laser and Trotec Laser
  • Hazard: Trotec Laser, under “Materials you should not process with a laser”: There are some materials that should not be processed with a laser engraver or a laser cutter because of their chemical make-up. Processing these materials creates dangerous gases or dust. (Which materials are not suitable for laser cutting and engraving?, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Ventilation: Creality, under “Security Statement”: Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Check the composition: Trotec Laser, under “Materials you should not process with a laser”: Leather and artificial leather that contains chromium (VI) (Which materials are not suitable for laser cutting and engraving?, read 2026-09-21)
  • Check the composition: Creality, under “Parameters”: Cardboard, wood, bamboo, rubber, leather, fabric, acrylic, plastic, etc. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Check the composition: Epilog Laser, under “What happens if you engrave or cut something containing hydrogen or vinyl chloride?”: To protect your health and the life of your machine, always obtain a MSDS for materials about which you are uncertain. (Material Safety and your Laser, read 2026-09-21)

Tanning method not stated by Creality Falcon.

Reviewed 2026-09-21; next review due 2026-12-20.

Wood

Fire risk and ventilate · 5 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Ventilation: Creality, under “Security Statement”: Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Common questions

Can I use a row on another machine?

Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.

Why are some fields marked not specified?

The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.

Why are some combinations absent?

CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.

Source documents

Sources (5)
Epilog Laser: Reducing Fire Hazards with your Laser (3 excerpts)

Reducing Fire Hazards with your Laser

Publication date not printed by Epilog Laser · Read · Captured

  1. Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser.

    Epilog Laser, Reducing Fire Hazards with your Laser, Introduction. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Epilog Laser: Material Safety and your Laser (1 excerpt)

Material Safety and your Laser

Publication date not printed by Epilog Laser · Read · Captured

  1. To protect your health and the life of your machine, always obtain a MSDS for materials about which you are uncertain.

    Epilog Laser, Material Safety and your Laser, What happens if you engrave or cut something containing hydrogen or vinyl chloride?. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Creality: Creality Falcon2 (12W/22W/40W) User Manual (4 excerpts)

Creality Falcon2 (12W/22W/40W) User Manual

Publication date not printed by Creality · Read · Captured

  1. When a laser engraver engraves or cuts materials, it casts a high-density laser beam that heats the surface to vaporize materials without burning them. But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Cardboard, wood, bamboo, rubber, leather, fabric, acrylic, plastic, etc.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Parameters. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. 14. It is forbidden to leave it unattended while the machine is working.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. 11. Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Monport: Model ONYX-R (6 excerpts)

Model ONYX-R

Publication date not printed by Monport · Read · Captured

  1. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  6. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Trotec Laser: Which materials are not suitable for laser cutting and engraving? (2 excerpts)

Which materials are not suitable for laser cutting and engraving?

Publication date not printed by Trotec Laser · Read · Captured

  1. Leather and artificial leather that contains chromium (VI)

    Trotec Laser, Which materials are not suitable for laser cutting and engraving?, Materials you should not process with a laser. Publication date not printed by Trotec Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. There are some materials that should not be processed with a laser engraver or a laser cutter because of their chemical make-up. Processing these materials creates dangerous gases or dust.

    Trotec Laser, Which materials are not suitable for laser cutting and engraving?, Materials you should not process with a laser. Publication date not printed by Trotec Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.
