Cast vs extruded acrylic for laser cutting
For CO2 work, Trotec describes cast acrylic as a choice for white, high-contrast engraving and extruded acrylic as a choice for tighter thickness consistency. Both need a recipe matched to the machine and sheet. Choose by the intended finish, then confirm the supplier's material identity and actual thickness. CutChart cites Trotec here and has not cut either sheet.

On this page
Choose for the finished part
Trotec's acrylic processing guide distinguishes two useful tradeoffs in CO2 work. Cast acrylic gives a white engraved appearance. Extruded acrylic has tighter thickness consistency and a less contrasting engraved appearance.
On a narrow screen, scroll the table sideways.
| Job priority | Trotec's material distinction | Question for your supplier |
|---|---|---|
| Visible white engraving | Cast acrylic favors engraving contrast. | Is this exact product cast acrylic? |
| Fitted parts | Extruded acrylic has tighter thickness consistency. | What thickness range does this sheet carry? |
| Cut-edge appearance | Trotec discusses edge quality for both types. | Which machine and process does the finish claim describe? |
These are material-selection distinctions. They do not supply a cutting recipe for another machine. For the parameters CutChart does publish, acrylic laser settings collects the acrylic rows by machine, and each row states the operation it was printed for.
Keep the sheet identity with the job
Keep the supplier name, product identifier, cast or extruded label, color, stated thickness and any masking description. Add the material safety document. If an offcut lacks a label, leave its identity unresolved instead of naming it from appearance.
Record the actual thickness used when evaluating a fitted part. A nominal thickness in a shopping listing and the sheet you are holding are separate entries in the job note. This is CutChart's suggested record format, not a supplier tolerance specification.
Check the laser family before copying a result
LightBurn's wavelength overview says blue diodes struggle with transparent or light-colored materials. A CO2 result does not establish a result for a blue-diode module. Keep the laser source alongside the cast or extruded label.
The two families are published as separate references here. Read the CO2 acrylic rows and the diode acrylic rows as separate records, and see what a CO2 machine does differently or what a diode machine does differently before moving a value between them.
See what each laser can cut or mark for the distinction between a broad material listing and a documented operation. The optical-watt decoder helps identify published power fields; it does not predict acrylic thickness.
Save a preset with enough context to revisit it
Use separate names for separate sheets and machines in your records. Include the source URL and the date you read it, then write down which conditions the document actually states. Leave missing conditions visible.
The LightBurn Material Library guide explains saving a preset. Before copying a speed, use the unit converter to compare distance and time units. If a cut fails, the troubleshooting guide helps you record the failure before changing the setup.
Buy the material named in the record
Use a shopping listing to identify a supplier and exact blank. Save the product code, sheet type, color, nominal thickness, dimensions and pack quantity before ordering. A title such as laser plywood or acrylic sheet leaves useful questions unanswered. Your record should also state which supplier document answers each question.
On a narrow screen, scroll the table sideways.
| Blank or supply | Ask the supplier | Keep unresolved until answered |
|---|---|---|
| Acrylic sheet | Is the sheet cast or extruded, and what is the exact product code? | An acrylic title alone does not establish the type. |
| Plywood or wood blank | Which species, construction, adhesive and surface finish does this SKU use? | A similar thickness does not identify the same material. |
| Coated or adhesive-backed sheet | What are the coating, film and adhesive, and where is their material documentation? | An engraving claim does not identify every layer. |
| Replacement batch | Does it retain the same product code, composition and thickness specification? | A saved preset does not verify a new batch. |
Epilog's material compatibility guidance asks users to obtain the material safety data sheet. Keep that evidence beside the exact supplier SKU. An Amazon product description can help identify an item; it does not replace the material document or your machine's instructions.
Record thickness and the measuring tool
Keep nominal thickness and your measured thickness as separate fields. Write down the units, tool model, displayed resolution and the tool maker's accuracy specification. Read the accuracy specification separately from the number of decimal places on the display. Leave any unstated specification blank and consult the tool's manual before relying on it.
CutChart suggests recording several labeled locations on the sheet and retaining those observations with the job. This checklist does not prescribe a sampling plan, promise a fit or supply a correction factor. Record your observations without changing the source-published thickness printed in a settings row.
For wood, compare the material identity against the wood reference. For a laminated blank, start with the plywood reference. The safety material index keeps material restrictions separate from buying decisions. Buying a blank never creates a tested recipe or a new material admission on CutChart.
Common questions
Which acrylic gives a white engraved finish?
Trotec describes cast acrylic as producing white, high-contrast engraving in its CO2 guidance. The exact sheet and process still need checking.
Can I reuse the same preset for cast and extruded acrylic?
Keep separate records until your machine and material documents establish a match. The cast or extruded label alone does not supply a suitable speed or power.
