xTool D1 Pro Settings for Acrylic: 2 to 3 mm

xTool documents 19 speed and power settings for acrylic on the D1 Pro. CutChart has not tested them; it read the maker’s documents on 2026-10-02.

Diode only · safety ↓ · sources ↓

19 documented rows match these filters.

Source-documented settings for acrylic on the D1 Pro

About these numbers

Manufacturer-published reference parameters, not tested by CutChart

Speed: the figure the publisher printed, in bold, with mm/min converted under it. Type the number whose unit matches the speed box in your laser software. Not sure? Convert it here.

D1 Pro 5W

D1 Pro 5W · Dunkelrote Acrylglasplatte (undurchsichtig, glänzend)

D1 Pro 5W, Dunkelrote Acrylglasplatte (undurchsichtig, glänzend): 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 5W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)cut1 mm/s = 60 mm/min100%3
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 5W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)fill50 mm/s = 3000 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: 3 mm

Not specified by xTool for any row here: air assist, focus and lens; line interval on fill rows.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

D1 Pro 10W

D1 Pro 10W · Dunkelrote Acrylglasplatte (undurchsichtig, glänzend)

D1 Pro 10W, Dunkelrote Acrylglasplatte (undurchsichtig, glänzend): 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 10W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)cut3 mm/s = 180 mm/min100%4
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 10W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)engrave40 mm/s = 2400 mm/min40%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 10W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)fill50 mm/s = 3000 mm/min80%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 10W · Rote Acrylglasplatte (transparent, glänzend)

D1 Pro 10W, Rote Acrylglasplatte (transparent, glänzend): 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 10W3 mmRote Acrylglasplatte (transparent, glänzend)cut3 mm/s = 180 mm/min100%4
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 10W3 mmRote Acrylglasplatte (transparent, glänzend)engrave50 mm/s = 3000 mm/min40%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 10W3 mmRote Acrylglasplatte (transparent, glänzend)fill50 mm/s = 3000 mm/min60%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: 3 mm

Not specified by xTool for any row here: air assist, focus and lens; line interval on fill and engrave rows.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

D1 Pro 20W

D1 Pro 20W · Braune Acrylglasplatte undurchsichtig glänzend

D1 Pro 20W, Braune Acrylglasplatte undurchsichtig glänzend: 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W2 mmBraune Acrylglasplatte undurchsichtig glänzendcut5 mm/s = 300 mm/min100%3
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W2 mmBraune Acrylglasplatte undurchsichtig glänzendengrave40 mm/s = 2400 mm/min50%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W2 mmBraune Acrylglasplatte undurchsichtig glänzendfill50 mm/s = 3000 mm/min40%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Dunkelrote Acrylglasplatte (undurchsichtig, glänzend)

D1 Pro 20W, Dunkelrote Acrylglasplatte (undurchsichtig, glänzend): 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)cut3 mm/s = 180 mm/min100%3
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)engrave40 mm/s = 2400 mm/min30%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)fill50 mm/s = 3000 mm/min40%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Rote Acrylglasplatte (transparent, glänzend)

D1 Pro 20W, Rote Acrylglasplatte (transparent, glänzend): 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmRote Acrylglasplatte (transparent, glänzend)cut3 mm/s = 180 mm/min100%3
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmRote Acrylglasplatte (transparent, glänzend)engrave40 mm/s = 2400 mm/min30%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmRote Acrylglasplatte (transparent, glänzend)fill100 mm/s = 6000 mm/min60%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Not specified by xTool for any row here: air assist, focus and lens; line interval on fill and engrave rows.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

D1 Pro 40W

D1 Pro 40W · Blutrotes Acrylglas

D1 Pro 40W, Blutrotes Acrylglas: 1 row, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 40W3 mmBlutrotes Acrylglascut5 mm/s = 300 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 40W · Schwarzes Acrylglas

D1 Pro 40W, Schwarzes Acrylglas: 1 row, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 40W3 mmSchwarzes Acrylglascut5 mm/s = 300 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

These values are identical to D1 Pro 40W's Schwarzes Acrylglas table above: both makers' documents print the same numbers.

Every row: cut · 3 mm · 1 pass

Not specified by xTool for any row here: air assist, focus and lens.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

Material safety statements from the sources

Quoted from laser makers' documents about each material. Not a complete safety procedure.

Acrylic

Fire risk · 3 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Introduction”: Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Common questions

Can I use a row on another machine?

Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.

Why are some fields marked not specified?

The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.

Why are some combinations absent?

CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.

Source documents

Sources (3)
Epilog Laser: Reducing Fire Hazards with your Laser (2 excerpts)

Reducing Fire Hazards with your Laser

Publication date not printed by Epilog Laser · Read · Captured

  1. Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser.

    Epilog Laser, Reducing Fire Hazards with your Laser, Introduction. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Creality: Creality Falcon2 (12W/22W/40W) User Manual (1 excerpt)

Creality Falcon2 (12W/22W/40W) User Manual

Publication date not printed by Creality · Read · Captured

  1. 14. It is forbidden to leave it unattended while the machine is working.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

xTool: Materialeinstellungen für xTool Maschinen (19 excerpts)

Materialeinstellungen für xTool Maschinen

Publication date not printed by xTool · Read · Captured

  1. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Schnitt | D1 Pro 10W | 100 / 3 / 4

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Vektorgravur | D1 Pro 10W | 40 / 40 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Rastergravur | D1 Pro 10W | 80 / 50 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Rote Acrylglasplatte (transparent, glänzend) | 3.0 | Schnitt | D1 Pro 10W | 100 / 3 / 4

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Rote Acrylglasplatte (transparent, glänzend) | 3.0 | Vektorgravur | D1 Pro 10W | 40 / 50 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  6. Rote Acrylglasplatte (transparent, glänzend) | 3.0 | Rastergravur | D1 Pro 10W | 60 / 50 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  7. Braune Acrylglasplatte undurchsichtig glänzend | 2.0 | Schnitt | D1 Pro 20W | 100 / 5 / 3

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  8. Braune Acrylglasplatte undurchsichtig glänzend | 2.0 | Vektorgravur | D1 Pro 20W | 50 / 40 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  9. Braune Acrylglasplatte undurchsichtig glänzend | 2.0 | Rastergravur | D1 Pro 20W | 40 / 50 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  10. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Schnitt | D1 Pro 20W | 100 / 3 / 3

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  11. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Vektorgravur | D1 Pro 20W | 30 / 40 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  12. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Rastergravur | D1 Pro 20W | 40 / 50 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  13. Rote Acrylglasplatte (transparent, glänzend) | 3.0 | Schnitt | D1 Pro 20W | 100 / 3 / 3

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  14. Rote Acrylglasplatte (transparent, glänzend) | 3.0 | Vektorgravur | D1 Pro 20W | 30 / 40 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  15. Rote Acrylglasplatte (transparent, glänzend) | 3.0 | Rastergravur | D1 Pro 20W | 60 / 100 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  16. Blutrotes Acrylglas | 3.0 | Schnitt | D1 Pro 40W | 100 / 5 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  17. Schwarzes Acrylglas | 3.0 | Schnitt | D1 Pro 40W | 100 / 5 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  18. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Schnitt | D1 Pro 5W | 100 / 1 / 3

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  19. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Rastergravur | D1 Pro 5W | 100 / 50 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Cite this page: xTool D1 Pro Settings for Acrylic: 2 to 3 mm. CutChart. https://cutchart.com/settings/acrylic/xtool-d1-pro/ (sources read 2026-10-02).

Reference information only. Follow the instructions for your exact machine and material. A listed setting does not establish that a job is safe. Read the safety limits.
