CO2 Laser Cutting & Engraving Settings for Acrylic

Monport and OMTech document 9 speed and power settings for acrylic on CO2 lasers. CutChart has not tested them; it read the makers’ documents on 2026-09-21.

safety ↓ · sources ↓

9 documented rows match these filters.

Source-documented settings for acrylic on CO2 lasers

About these numbers

Manufacturer-published reference parameters, not tested by CutChart

Speed: the figure the publisher printed, in bold, with mm/min converted under it. Type the number whose unit matches the speed box in your laser software. Not sure? Convert it here.

Monport 40W CO2 Laser Engraver

Monport 40W CO2 Laser Engraver · Acrylic

Monport 40W CO2 Laser Engraver, Acrylic: 5 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
Monport 40W CO2 Laser Engraver1 mmAcryliccut13 mm/s = 780 mm/min20%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Monport 40W CO2 Laser Engraver2 mmAcryliccut11 mm/s = 660 mm/min23%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Monport 40W CO2 Laser Engraver3 mmAcryliccut9 mm/s = 540 mm/min25%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Monport 40W CO2 Laser Engraver4 mmAcryliccut7 mm/s = 420 mm/min35%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
Monport 40W CO2 Laser Engraver5 mmAcryliccut4 mm/s = 240 mm/min45%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: cut

Not specified by Monport for any row here: passes, air assist, focus and lens.

Source: Monport, read 2026-09-21; reviewed 2026-09-21. Document: Monport 40W CO2 Laser Engraver Recommended Parameters.

OMTech Polar 350

OMTech Polar 350 · Acrylic

OMTech Polar 350, Acrylic: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
OMTech Polar 3503 mmAcryliccut35 mm/s = 2100 mm/min90%Not specified by OMTech
  • Air assist: Not specified by OMTech
  • Focus: Not specified by OMTech
  • Lens: Not specified by OMTech
OMTech, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
OMTech Polar 3503 mmAcrylicengrave500 mm/s = 30000 mm/min50%Not specified by OMTech
  • Air assist: Not specified by OMTech
  • Focus: Not specified by OMTech
  • Lens: Not specified by OMTech
  • Line interval: Not specified by OMTech
OMTech, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: 3 mm

Not specified by OMTech for any row here: passes, air assist, focus and lens; line interval on engrave rows.

Source: OMTech, read 2026-09-21; reviewed 2026-09-21. Document: POLAR 350 | 50W | CO2 Desktop Laser Engraver.

ONYX-R

ONYX-R · Acrylic

ONYX-R, Acrylic: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
ONYX-R3 mmAcryliccut35 mm/s = 2100 mm/min90%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
ONYX-R3 mmAcrylicengrave500 mm/s = 30000 mm/min50%Not specified by Monport
  • Air assist: Not specified by Monport
  • Focus: Not specified by Monport
  • Lens: Not specified by Monport
  • Line interval: Not specified by Monport
Monport, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

These values are identical to the OMTech Polar 350 table above: both makers' documents print the same numbers.

Every row: 3 mm

Not specified by Monport for any row here: passes, air assist, focus and lens; line interval on engrave rows.

Source: Monport, read 2026-09-21; reviewed 2026-09-21. Document: Model ONYX-R.

Material safety statements from the sources

Quoted from laser makers' documents about each material. Not a complete safety procedure.

Acrylic

Fire risk · 3 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Introduction”: Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Common questions

Can I use a row on another machine?

Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.

Why are some fields marked not specified?

The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.

Why are some combinations absent?

CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.

Source documents

Sources (5)
Epilog Laser: Reducing Fire Hazards with your Laser (2 excerpts)

Reducing Fire Hazards with your Laser

Publication date not printed by Epilog Laser · Read · Captured

  1. Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser.

    Epilog Laser, Reducing Fire Hazards with your Laser, Introduction. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Creality: Creality Falcon2 (12W/22W/40W) User Manual (1 excerpt)

Creality Falcon2 (12W/22W/40W) User Manual

Publication date not printed by Creality · Read · Captured

  1. 14. It is forbidden to leave it unattended while the machine is working.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Monport: Monport 40W CO2 Laser Engraver Recommended Parameters (5 excerpts)

Monport 40W CO2 Laser Engraver Recommended Parameters

Publication date not printed by Monport · Read · Captured

  1. Cutting Thickness of Acrylic Material Thickness 1mm 2mm 3mm 4mm 5mm Speed(mm/s) 13 11 9 7 4 Power % 20 23 25 35 45

    Monport, Monport 40W CO2 Laser Engraver Recommended Parameters, Cutting Thickness of Acrylic. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Cutting Thickness of Acrylic Material Thickness 1mm 2mm 3mm 4mm 5mm Speed(mm/s) 13 11 9 7 4 Power % 20 23 25 35 45

    Monport, Monport 40W CO2 Laser Engraver Recommended Parameters, Cutting Thickness of Acrylic. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Cutting Thickness of Acrylic Material Thickness 1mm 2mm 3mm 4mm 5mm Speed(mm/s) 13 11 9 7 4 Power % 20 23 25 35 45

    Monport, Monport 40W CO2 Laser Engraver Recommended Parameters, Cutting Thickness of Acrylic. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Cutting Thickness of Acrylic Material Thickness 1mm 2mm 3mm 4mm 5mm Speed(mm/s) 13 11 9 7 4 Power % 20 23 25 35 45

    Monport, Monport 40W CO2 Laser Engraver Recommended Parameters, Cutting Thickness of Acrylic. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Cutting Thickness of Acrylic Material Thickness 1mm 2mm 3mm 4mm 5mm Speed(mm/s) 13 11 9 7 4 Power % 20 23 25 35 45

    Monport, Monport 40W CO2 Laser Engraver Recommended Parameters, Cutting Thickness of Acrylic. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Monport: Model ONYX-R (2 excerpts)

Model ONYX-R

Publication date not printed by Monport · Read · Captured

  1. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Attachment 1 Material Acrylic Basswood Canvas Cardboard Leather MDF Power (W) 50% 50% 25% 45% 30% 40% Engraving Speed 500 500 500 500 500 500 (mm/s) 100% 100% 100% 100% 100% 100% Power (W) 90% 90% 60% 90% 90% 90% Cutting Speed 35 65 350 200 80 30 (mm/s) 7% 13% 70% 40% 16% 6% Rec. Thickness (mm) 3 3 0.2 2 1.5 3 Resolution (dpi) 400 400 300 400 400 300

    Monport, Model ONYX-R, Attachment 1. Publication date not printed by Monport · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

OMTech: POLAR 350 | 50W | CO2 Desktop Laser Engraver (2 excerpts)

POLAR 350 | 50W | CO2 Desktop Laser Engraver

Publication date not printed by OMTech · Read · Captured

  1. Acrylic 25 50% 500 100% 45 90% 35 7% 3 400

    OMTech, POLAR 350 | 50W | CO2 Desktop Laser Engraver, Average Engraving Settings. Publication date not printed by OMTech · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Acrylic 25 50% 500 100% 45 90% 35 7% 3 400

    OMTech, POLAR 350 | 50W | CO2 Desktop Laser Engraver, Average Engraving Settings. Publication date not printed by OMTech · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Cite this page: CO2 Laser Cutting & Engraving Settings for Acrylic. CutChart. https://cutchart.com/settings/acrylic/co2/ (sources read 2026-09-21).

Reference information only. Follow the instructions for your exact machine and material. A listed setting does not establish that a job is safe. Read the safety limits.
