20W diode Laser Settings Chart

Ortur and xTool document 38 speed and power settings on diode lasers. CutChart has not tested them; it read the makers’ documents from 2026-09-21 to 2026-10-02.

safety ↓ · sources ↓

Shopping for a diode laser? See the TwoTrees shop option.

38 documented rows match these filters.

Source-documented settings on diode lasers

About these numbers

Manufacturer-published reference parameters, not tested by CutChart

Speed: the figure the publisher printed, in bold, with the other unit converted under it. Type the number whose unit matches the speed box in your laser software. Not sure? Convert it here.

D1 Pro 20W

D1 Pro 20W · Birkensperrholz

D1 Pro 20W, Birkensperrholz: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmBirkensperrholzcut6 mm/s = 360 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W6 mmBirkensperrholzcut4 mm/s = 240 mm/min100%3
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Braune Acrylglasplatte undurchsichtig glänzend

D1 Pro 20W, Braune Acrylglasplatte undurchsichtig glänzend: 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W2 mmBraune Acrylglasplatte undurchsichtig glänzendcut5 mm/s = 300 mm/min100%3
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W2 mmBraune Acrylglasplatte undurchsichtig glänzendengrave40 mm/s = 2400 mm/min50%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W2 mmBraune Acrylglasplatte undurchsichtig glänzendfill50 mm/s = 3000 mm/min40%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Dunkelrote Acrylglasplatte (undurchsichtig, glänzend)

D1 Pro 20W, Dunkelrote Acrylglasplatte (undurchsichtig, glänzend): 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)cut3 mm/s = 180 mm/min100%3
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)engrave40 mm/s = 2400 mm/min30%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmDunkelrote Acrylglasplatte (undurchsichtig, glänzend)fill50 mm/s = 3000 mm/min40%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Kiefernsperrholz

D1 Pro 20W, Kiefernsperrholz: 1 row, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmKiefernsperrholzcut5 mm/s = 300 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Lindensperrholz

D1 Pro 20W, Lindensperrholz: 4 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmLindensperrholzcut6 mm/s = 360 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W6 mmLindensperrholzcut6 mm/s = 360 mm/min100%3
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmLindensperrholzengrave60 mm/s = 3600 mm/min80%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmLindensperrholzfill100 mm/s = 6000 mm/min60%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Mahagonisperrholz

D1 Pro 20W, Mahagonisperrholz: 1 row, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmMahagonisperrholzcut6 mm/s = 360 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Mandschurisches Eschensperrholz

D1 Pro 20W, Mandschurisches Eschensperrholz: 1 row, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmMandschurisches Eschensperrholzcut4 mm/s = 240 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Rote Acrylglasplatte (transparent, glänzend)

D1 Pro 20W, Rote Acrylglasplatte (transparent, glänzend): 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmRote Acrylglasplatte (transparent, glänzend)cut3 mm/s = 180 mm/min100%3
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmRote Acrylglasplatte (transparent, glänzend)engrave40 mm/s = 2400 mm/min30%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W3 mmRote Acrylglasplatte (transparent, glänzend)fill100 mm/s = 6000 mm/min60%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
  • Line interval: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · Walnusssperrholz

D1 Pro 20W, Walnusssperrholz: 2 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmWalnusssperrholzcut4 mm/s = 240 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
D1 Pro 20W6 mmWalnusssperrholzcut60 mm/s = 3600 mm/min80%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

D1 Pro 20W · White oak plywood

D1 Pro 20W, White oak plywood: 1 row, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
D1 Pro 20W3 mmWhite oak plywoodcut5 mm/s = 300 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

These values are identical to D1 Pro 20W's White oak plywood table above: both makers' documents print the same numbers.

Not specified by xTool for any row here: air assist, focus and lens; line interval on fill and engrave rows.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

LU3-20A/B (20W)

LU3-20A/B (20W) · Pine

LU3-20A/B (20W), Pine: 7 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
LU3-20A/B (20W)3 mmPinecut500 mm/min (8.33 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)5 mmPinecut350 mm/min (5.83 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)8 mmPinecut200 mm/min (3.33 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)10 mmPinecut150 mm/min (2.5 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)12 mmPinecut100 mm/min (1.67 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)15 mmPinecut100 mm/min (1.67 mm/s)100%2
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)19 mmPinecut100 mm/min (1.67 mm/s)100%3
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

LU3-20A/B (20W) · Plywood

LU3-20A/B (20W), Plywood: 6 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
LU3-20A/B (20W)1.6 mmPlywoodcut600 mm/min (10 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)2.8 mmPlywoodcut500 mm/min (8.33 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)5 mmPlywoodcut350 mm/min (5.83 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)8 mmPlywoodcut200 mm/min (3.33 mm/s)100%1
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)10 mmPlywoodcut250 mm/min (4.17 mm/s)100%2
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
LU3-20A/B (20W)15 mmPlywoodcut200 mm/min (3.33 mm/s)100%2
  • Air assist: Not specified by Ortur
  • Focus: Not specified by Ortur
  • Lens: Not specified by Ortur
Ortur, read 2026-09-21. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

Every row: cut

Not specified by Ortur for any row here: air assist, focus and lens.

Source: Ortur, read 2026-09-21; reviewed 2026-09-21. Document: Ortur LightBurn Material Settings.

xTool S1 20W blue module

xTool S1 20W blue module · Lindenholz (basswood, as printed)

xTool S1 20W blue module, Lindenholz: 3 rows, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
xTool S1 20W blue module3 mmLindenholzcut7 mm/s = 420 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 20W blue module6 mmLindenholzcut4 mm/s = 240 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.
xTool S1 20W blue module10 mmLindenholzcut3 mm/s = 180 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

xTool S1 20W blue module · Schwarzes Acryl

xTool S1 20W blue module, Schwarzes Acryl: 1 row, each with the thickness its publisher printed.
MachineThicknessMaterial as printedOperationSpeedPowerPassesNot printed by the publisherSource
xTool S1 20W blue module3 mmSchwarzes Acrylcut4 mm/s = 240 mm/min100%1
  • Air assist: Not specified by xTool
  • Focus: Not specified by xTool
  • Lens: Not specified by xTool
xTool, read 2026-10-02. Manufacturer-published reference parameters, not tested by CutChart; reviewed 2026-09-21.

These values are identical to the D1 Pro 20W table above: both makers' documents print the same numbers.

Every row: cut · 1 pass

Not specified by xTool for any row here: air assist, focus and lens.

Source: xTool, read 2026-10-02; reviewed 2026-09-21. Document: Materialeinstellungen für xTool Maschinen.

Every row on this page belongs to a 20 W diode configuration whose own documents state that wattage: LU3-20A/B (20W), D1 Pro 20W, xTool S1 20W blue module. Some of these documents print the wattage as a module label rather than a stated optical measurement; the machine table on each variant states which basis its publisher printed. A machine whose documents state no wattage on either basis has no row here.

Material safety statements from the sources

Quoted from laser makers' documents about each material. Not a complete safety procedure.

Acrylic

Fire risk · 3 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Introduction”: Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Plywood

Fire risk, ventilate and check what the material is made of · 5 statements from Creality and Epilog Laser
  • Fire: Creality, under “Security Statement”: But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Never operate the laser system unattended. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Ventilation: Creality, under “Security Statement”: Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Check the composition: Epilog Laser, under “What happens if you engrave or cut something containing hydrogen or vinyl chloride?”: To protect your health and the life of your machine, always obtain a MSDS for materials about which you are uncertain. (Material Safety and your Laser, read 2026-09-21)

The cited safety pages name wood but not plywood or its adhesive; the Creality Falcon parameter rows print Walnut Plywood and Rosewood Plywood without a glue type.

Reviewed 2026-09-21; next review due 2026-12-20.

Wood

Fire risk and ventilate · 5 statements from Creality and Epilog Laser
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Epilog Laser, under “Warnings and Recommendations”: Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire. (Reducing Fire Hazards with your Laser, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Fire: Creality, under “Security Statement”: It is forbidden to leave it unattended while the machine is working. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)
  • Ventilation: Creality, under “Security Statement”: Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment. (Creality Falcon2 (12W/22W/40W) User Manual, read 2026-09-21)

Reviewed 2026-09-21; next review due 2026-12-20.

Common questions

Can I use a row on another machine?

Each row belongs to the stated machine and configuration. A matching wattage or material name does not establish a setting for another machine.

Why are some fields marked not specified?

The publisher’s table prints speed, power and thickness, and sometimes passes, but not air assist, focus or lens. CutChart shows each unprinted field as not specified rather than filling it in.

Why are some combinations absent?

CutChart publishes a row only when its source, exact machine, material, operation and a sourced material-safety statement meet the reference requirements. An absent row is an unknown answer.

Source documents

Sources (5)
Epilog Laser: Reducing Fire Hazards with your Laser (4 excerpts)

Reducing Fire Hazards with your Laser

Publication date not printed by Epilog Laser · Read · Captured

  1. Many materials are susceptible to igniting; however, acrylic (in all its forms), has shown to be especially flammable when vector cutting with the laser.

    Epilog Laser, Reducing Fire Hazards with your Laser, Introduction. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Utilizing the Air Assist feature will reduce the instance of flare-ups when working with flammable materials such as acrylic and wood.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Since most users cut wood and acrylic, these small pieces that fall into the table tray act just like kindling and can ignite and start a fire.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Never operate the laser system unattended.

    Epilog Laser, Reducing Fire Hazards with your Laser, Warnings and Recommendations. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Epilog Laser: Material Safety and your Laser (1 excerpt)

Material Safety and your Laser

Publication date not printed by Epilog Laser · Read · Captured

  1. To protect your health and the life of your machine, always obtain a MSDS for materials about which you are uncertain.

    Epilog Laser, Material Safety and your Laser, What happens if you engrave or cut something containing hydrogen or vinyl chloride?. Publication date not printed by Epilog Laser · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Creality: Creality Falcon2 (12W/22W/40W) User Manual (3 excerpts)

Creality Falcon2 (12W/22W/40W) User Manual

Publication date not printed by Creality · Read · Captured

  1. When a laser engraver engraves or cuts materials, it casts a high-density laser beam that heats the surface to vaporize materials without burning them. But most materials are inherently flammable and can be ignited, which may burn the machine and the surroundings.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. 14. It is forbidden to leave it unattended while the machine is working.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. 11. Smoke or smells may be produced during laser engraving and cutting. It is recommended to operate in a well-ventilated environment.

    Creality, Creality Falcon2 (12W/22W/40W) User Manual, Security Statement. Publication date not printed by Creality · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Ortur: Ortur LightBurn Material Settings (13 excerpts)

Ortur LightBurn Material Settings

Publication date not printed by Ortur · Read · Captured

  1. Image Mode: Line Speed(mm/m): 150mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 2

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Image Mode: Line Speed(mm/m): 100mm Power Min(%): 100 Perform Multiple Passes: 3

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Image Mode: Line Speed(mm/m): 500mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  6. Image Mode: Line Speed(mm/m): 350mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  7. Image Mode: Line Speed(mm/m): 200mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  8. Image Mode: Line Speed(mm/m): 250mm Power Min(%): 100 Perform Multiple Passes: 2

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  9. Image Mode: Line Speed(mm/m): 200mm Power Min(%): 100 Perform Multiple Passes: 2

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  10. Image Mode: Line Speed(mm/m): 600mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  11. Image Mode: Line Speed(mm/m): 500mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  12. Image Mode: Line Speed(mm/m): 350mm Power Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  13. Image Mode: Line Speed(mm/m): 200mm P ower Min(%): 100 Perform Multiple Passes: 1

    Ortur, Ortur LightBurn Material Settings, LightBurn Settings for Cutting. Publication date not printed by Ortur · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

xTool: Materialeinstellungen für xTool Maschinen (25 excerpts)

Materialeinstellungen für xTool Maschinen

Publication date not printed by xTool · Read · Captured

  1. Birkensperrholz | 3.0 | Schnitt | D1 Pro 20W | 100 / 6 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  2. Birkensperrholz | 6.0 | Schnitt | D1 Pro 20W | 100 / 4 / 3

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  3. Braune Acrylglasplatte undurchsichtig glänzend | 2.0 | Schnitt | D1 Pro 20W | 100 / 5 / 3

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  4. Braune Acrylglasplatte undurchsichtig glänzend | 2.0 | Vektorgravur | D1 Pro 20W | 50 / 40 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  5. Braune Acrylglasplatte undurchsichtig glänzend | 2.0 | Rastergravur | D1 Pro 20W | 40 / 50 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  6. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Schnitt | D1 Pro 20W | 100 / 3 / 3

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  7. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Vektorgravur | D1 Pro 20W | 30 / 40 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  8. Dunkelrote Acrylglasplatte (undurchsichtig, glänzend) | 3.0 | Rastergravur | D1 Pro 20W | 40 / 50 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  9. Kiefernsperrholz | 3.0 | Schnitt | D1 Pro 20W | 100 / 5 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  10. Lindensperrholz | 3.0 | Schnitt | D1 Pro 20W | 100 / 6 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  11. Lindensperrholz | 3.0 | Vektorgravur | D1 Pro 20W | 80 / 60 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  12. Lindensperrholz | 3.0 | Rastergravur | D1 Pro 20W | 60 / 100 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  13. Lindensperrholz | 6.0 | Schnitt | D1 Pro 20W | 100 / 6 / 3

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  14. Mahagonisperrholz | 3.0 | Schnitt | D1 Pro 20W | 100 / 6 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  15. Mandschurisches Eschensperrholz | 3.0 | Schnitt | D1 Pro 20W | 100 / 4 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  16. Rote Acrylglasplatte (transparent, glänzend) | 3.0 | Schnitt | D1 Pro 20W | 100 / 3 / 3

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  17. Rote Acrylglasplatte (transparent, glänzend) | 3.0 | Vektorgravur | D1 Pro 20W | 30 / 40 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  18. Rote Acrylglasplatte (transparent, glänzend) | 3.0 | Rastergravur | D1 Pro 20W | 60 / 100 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  19. Walnusssperrholz | 3.0 | Schnitt | D1 Pro 20W | 100 / 4 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  20. Walnusssperrholz | 6.0 | Schnitt | D1 Pro 20W | 80 / 60 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  21. White oak plywood | 3.0 | Schnitt | D1 Pro 20W | 100 / 5 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool D1 Pro. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  22. Lindenholz | 10.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100/ 3 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  23. Lindenholz | 3.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 7 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  24. Lindenholz | 6.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 4 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

  25. Schwarzes Acryl | 3.0 | Vektorschnitt | 20 W Blaulicht-Laser | 100 / 4 / 1

    xTool, Materialeinstellungen für xTool Maschinen, xTool S1. Publication date not printed by xTool · Read · Captured . Read the named field and section in the cited document. The excerpt alone does not establish a complete cutting procedure.

Cite this page: 20W diode Laser Settings Chart. CutChart. https://cutchart.com/settings/diode/20w/ (sources read 2026-09-21 to 2026-10-02).

Reference information only. Follow the instructions for your exact machine and material. A listed setting does not establish that a job is safe. Read the safety limits.
